New Model 8T Diesel Forklift Truck CPCD80
| FOB Price: | 35,850.00 - 40,000.00 USD/Set |
|---|---|
| Supply Ability: | 100 Set/Sets per Month |
| Shipping: | 30 days upon payment |
| Payment Terms: | L/C, T/T |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | Nude Packs |
Quick Details
- Condition: New
- Brand Name: Dragon Machinery
- Model Number: CPCD80
- Type: Powered Pallet Truck
- Power Souce: Diesel Engine
- Rated Loading Capacity: 800kg
- Max. Lifting Height: 3000mm
- Min. Lifting Height: 165mm
- Fork Length: 1220mm
- Fork Width: 175mm
- Overall Dimensions: 3995X2050X4180mm
- Certification: CE
- After-sales Service Provided: Overseas service center available
- Load Center: 600mm
- Lifting Height: 3000
- Wheel Base: 2600
- Dead Weight: 11210kg
Specifications
8.0T counterbalance diesel forklifts, 8.0T internal combustion forklift, 8.0T diesel powered forklift, 8.0 ton diesel powered forklift, 8.0T diesel fired forklift truck, diesel fired forklift 8.0T capacity, 8 ton diesel forklifts, 8 ton diesel fork lift, diesel fork lift truck 8T capacity, 8000kg diesel forklift truck, 8000kg capacity diesel forklift truck, diesel powered forklift truck 8000kg capacity, 8000kg capacity diesel fired forklifts, 8.0 ton internal combustion forklift, 8T internal combustion fork lift truck, 8.0 ton counterbalanced diesel forklift truck, 8.0T diesel forklift, 8.0T diesel forklift truck, 8.0 ton diesel forklift, 8.0T capacity diesel forklift, 8.0T diesel fork lift truck
Features:
1. Intelligent Drive-monitoring System
The digital intelligent drive-monitoring system of our diesel forklift truck can facilitate obtaining the operation data of the diesel forklift easily, so as to achieve the whole-process control of the forklift.
2. Full Hydraulic Flexible Steering System
The full hydraulic steering system of our diesel forklifts can greatly reduce the fatigue of the operator. The steering system uses a horizontal oil cylinder on the compact steering axle and guarantees a reliable steering.
3. Classical Space Frame Structure
Our diesel forklift truck uses the classical YTO ASF space frame structure. It is ergonomically designed, aesthetic in appearance, compact in structure, and easy to operate.
4. Good Rear-view Visibility
The big arc design of the counterweight can improve the visibility of rear view and guarantee the optimum visibility when driving reversely.
5. Good-view Mast
The optimized rail section design of the mast enables the driver to enjoy a good and wide view.
Technical Specifications:
Model: CPCD80
Power Type: Diesel
Rated Capacity: 8000kg
Load Center: 600mm
Lifting Height: 3000mm
Mast Tilt Angel (F/R): 6/12 deg.
Front Overhang: 685mm
Wheel Base: 2600mm
Wheel Tread (F/R): 1535/1720mm
Dead Weight: 11210kg
Free Lift Height: 165mm
Min. Turning Radius: 3670mm
Min. Ground Clearance - Under Mast: 245mm
Min. Ground Clearance - Wheelbase Center: 230mm
Service Brake: Hydraulic Foot Pedal
Parking Brake: Mechanical Hand Lever
Lifting Speed (full-load): 320mm/s
Lowering Speed: Full-load < 600mm/s, No-load > 300mm/s
Travel Speed (no-load): 24km/h
Max. Gradeability (full-load): 20%
Max. Tractive Force (no-load): 43/33kN
Weight Distribution with load (F/R): 17590/1620kg
Weight Distribution without Load (F/R): 5380/5830kg
Engine Model: LR6B5-22
Engine Manufacturer: YTO
Engine Rated Power: 88.2kW/2200rpm
Max. Torque/rpm of Engine: 440N·m/1600rpm
Engine Displacement: 7.42L
Battery Voltage: 24V
Battery Capacity: 2X100Ah
Gearbox Transmission Type: Hydraulic torque converter
Gear Shift (F/R): II/II
Tyre Type: Pneumatic Tyres
TyreModel - Front: 8.25-20-14PR
Tyre Model - Rear: 8.25-20-14PR
ForkDimension: 75x175x1220mm
Overall Length (without fork): 3995mm
Overall Width: 2050mm
Overall Height - Mast Extended: 4180mm
Overall Height - Mast Lowered: 2695mm
Overall Height - Overhead Guard: 2550mm
Note:
1. Technical specifications are for standard models only.
2. Other optional accessories, functions and requirements are available upon request.
3. All specifications and design characteristics are subject to change without prior notice.
