Car Straightening Bench

Supply Ability:	100 Set/Sets per Month
Payment Terms:	L/C, T/T, Western Union

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China

Specifications

Car Straightening Bench (SINF10)

1. The platform is spliced with high quality steel plate through carbon dioxide welding, with high strength and good rigidity.
2. The tower are 360 degrees movable and flexibly, the cylinder works vertically without any components forces consumption, powerful and accurate tensile force.
3. Hydraulic system imported from American POWERTEAM with original packing makes it powerful and gives it a long useful life and a low failure rate.
4. Various measuring systems with high accuracy can be selected.

Technical Specification
Working Platform length	5200mm
Working Platform width	2000mm
Working Platform height	570mm
The max working presure of hydraulic system	70MPa
The max lifting force of the tower cylinder	95KN
The pulling range of the tower	360
The pressure of the air source	0.6~0.8MPa
M lifti i Max lifting weight	3600kg
Equipment gross weight	2400kg
Quantity in 20 feet container	7pcs
