Qingdao Promising International Co., Ltd.
China Manufacturer with main products: Mini Loader, Small Loader, Wheel Loader, Mini Front Loader, Small Front Loader, Articulated Loader, Forklift Truck, Forklift |
Semi-electric Pallet Stacker TA10-16
| FOB Price: | 10,000.00 - 20,000.00 USD/Set |
|---|---|
| Supply Ability: | 200 Set/Sets per Month |
| Shipping: | 30 days upon payment |
| Payment Terms: | L/C, T/T |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | Nude |
Quick Details
- Brand Name: Dragon Machienry
- Model Number: TA10-16
- Lift Drive / Actuation: Electric Motor
- Power Type: Semi-Electric
- Operation Type: Walkie
- Rated Load Capacity (kg): 1000
- Max. Lift Height (mm): 1600
- Load Capacity at Max. Height (kg): 1000
- Overall Length (mm): 1625
- Overall Width (mm): 824
- Height of Mast Extended (mm): 2075
Specifications
Semi-Electric Pallet Stacker (Semi-Electric Stacker Truck)
semi-electric walkie pallet stacker, semi electric stacker truck, pedestrian operated semi-electric pallet stacker, semi-electric pedestrian pallet stacker truck, semi-electric walkie stacker, semi electric pedestrian stacker, manual push stacker, manual push pallet stacker
Applications:
Semi-Electric Pallet Stacker or Semi Electric Stacker Truck is applicable to the stacking works in the narrow aisles and limited spaces and is the ideal tools for high-rack warehouses, supermarkets and workshops for pallet stacking and block stacking or to handle material horizontally and load/unload palletized goods, especially for the transportation of goods on single or double deck pallets for retail and manufacturing industry.
Features:
1. Narrow width design;
2. 180 degree rotatable for operation handle;
3. Reliable & durable;
4. Energy saving;
5. Perfect performance;
6. Low maintenance cost.
Technical Specifications:
Model: TA10-16
Power Type: Semi-Electric
Operation Type: Walkie
Rated Load Capacity: 1000 kg
Load Capacity at Max. Height : 1000 kg
Max. Lift Height: 1600 mm
Load Center: 450 mm
Wheel Type: Nylon
Front Wheel: Φ80*70 mm
Rear Wheel: Φ180*50 mm
Number of Wheels, Front/Rear: 2/2
Mast Type: Standard
Height of Mast Lowered: 2075 mm
Height of Mast Extended: 2075 mm
Min. Height of Fork Face: 90 mm
Overall Length: 1625 mm
Wheelbase: 1260 mm
Overall Width: 824 mm
Front/Rear Wheel Tread: 510/704 mm
Fork Dimensions (L*W*T) : 1000*160*58 mm
Fork Spread: 670 mm
Aisle Width with 800*1200 Pallet along Forks: 2205 mm
Min. Turning Radius: 1400 mm
Lift Motor: 1.6 (DC) kW
Battery: 12 V / 115 Ah
Battery Weight : 33 kg
Service Weight (with Battery): 333 kg
Note:
1. Technical specifications are for standard models only.
2. Other optional accessories, functions and requirements are available upon request.
3. All specifications and design characteristics are subject to change without prior notice.
