Vibrating Plate Compactor

FOB Price:	1,000.00 - 10,000.00 USD/Set
Supply Ability:	120 Set/Sets per Month
Shipping:	20 days after payment, ship from Qingdao by sea or air
Payment Terms:	T/T, Western Union

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Henan in China
Packaging Details:	Fumigation-free polywood case

Specifications

ZP series Vibrating Tables are designed to settle and compact dry bulk materials (granules and powders) to different mould and shapes in various types of containers.
The table and base is connected with air spring to make low noise and obvious damping effect.

Our vibrating table have been exported to a few foreign countries and regions with good quality and reasonable price.

Application

Their application provides either a sizeable increase in the net weight of the container or reducing in the container size with subsequent savings in shipping and storage space.
Vibrating table can be widely used in metallurgy, mould, food, chemical industries and Building material etc…

Features

Big power, big table; the maximum power 2.2KW X (4-5), vibrating force 120KN, 12ton of the moulding flask can be loaded, the maximum bearing capacity can be made up to 15ton.
Adjustable height of table, suitable for production line.
3-D vibration, can be control separately, suitable for complex casting product.
Can get the best effect of compaction when moulding, on condition that do not damage the mould.
Function of self locking, can permit extremely localized in production.

Technical parameter

Model	Table Size	Vibrating Points	Vibrating Fore (KN)	Power (KW)	Weight (KG)	Vibrating Frequency (HZ)	Vibration Acceleration (G)	Amplitude (MM)
ZP0.8X0.8	800X800	4	20	1.6	450	20-80	1-2	0.5-2
ZP1.0X1.0	1000X1000	6	30	2.4	600
ZP1.2X1.2	1200X1200	6	30	2.4	860

Vibrating table is non-standard equipment, can be customized as buyer’ s requested design. Have to choose suitable vibrating motor according to the loading weight of the table.
