8CH H.264 720P AHD DVRs DR-A7408M
| FOB Price: | 63.57 - 71.00 USD/Piece |
|---|---|
| Supply Ability: | 50,000 Piece/Pieces per Month |
| Shipping: | 12 working days |
| Payment Terms: | T/T, Western Union |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | 1pc/polybag, color box |
Quick Details
- Model Number: DR-A7408M
- High definition: 720P
- Analog Cameras: Support
- IP Cameras: Support
- AHD Cameras: Support
Specifications
CCTV Surveillance System 8CH H.264 720P AHD DVRs
Model NO
DR-A7408M
System
Video Compression Format
H.264
Main Processor
HI3531 + NVP1918C/6114
Video System
NTSC / PAL
Operation System
Embedded Linux
AHD Signal System
AHD-L (960H) / AHD (720P) (Analog High
Definition)
Video
Video Input
8CH BNC
Video Output
1 x VGA / 1 x HDMI (1920*1080)
Video Distance
75-3 cable up to 500 Meters
Audio
Audio Input
2CH RCA
Audio Output
1CH RCA
Bidirectional Talk
YES
Recording
Recording Channel
8CH 720P Real Time
Resolution
NTSC - D1 (704 x 480) / 720P (1280 x
720)
PAL - D1 (704 x 576) / 720P (1280 x
720)
Frame Rate
NTSC 30fps / PAL 25fps
Recording Mode
Manual / Alarm / Video Detection /
Continuous
Playback
Playback Channel
8CH 720P Real Time
Search Mode
Time / Date / Alarm / Motion Detection
/ Exact Search
Playback Mode
Normal Play / Fast Forward / Fast
Rewind / Frame by Frame
Playback Software
General H.264 Player V1.7.0.
Alarm
Alarm Input
N/A
Alarm Output
N/A
Storage
HDD Interface
1 x SATA Fixed HDD
Capability
SATA HDD up to 4TB each
Backup
USB Disk
2 x USB 2.0 port
SNAP Image
NO
Backup Format
H.264 (only for Playback Software -
General H.264 Player V1.7.0.)
Backup Mode
Network
download / Flash USB / movable HDD / SATA HDD / DVD-RW
PTZ
PTZ
1 x RS485
Protocol
PELCO-P / PELCO-D / HY / NEON /
PANASONIC / SAMSUNG / PHILIPS / SANLI / SANTACHI / SHARP / SONY / YAAN
Network
Interface
RJ45 port / 10M / 100M / 1,000Mbps
Ethernet
Protocol
TCP/IP, DHCP, DDNS, DNS, PPPoE, UPNP,
NTP, SMTP
CMS Program
General_CMS_Eng_V3.0.7.7.T
(up to 128 Video channels Platform)
Mobile Phone Support
iPhone / iPad, Android, BlackBerry,
Symbian, Windows Mobile Pro
Computer System Support
Windows 2000, XP,
Vista, 7 / Mac OS x 10.6/10.7
Compatible Browser
Google Chrome, Internet Explorer,
Mozilla Firefox, Safari (Mac)
3G/WIFI
3G/WIFI USB Dongle (Plug-and-Play)
Free DDNS (P2P)
P2P Function via iCloud server (http://)
IP Camera Protocol
ONVIF 2.3 Version Platform Protocol
(IP Camera)
Simultaneous
Remote Viewers
6 Users Online
Others
Operating Temperature
0°C ~ 55°C
Operating Humidity
10% ~ 90%
Dimension
300*235*45mm
Weight
1.80 KGS
USB Mouse
YES
HDD Screw
4 PCS (1 Pack)
CD Disk (software)
YES
Quick Start Guide (QSG)
YES
P2P Manual (QSG)
YES
Power Supply
DC12V/2A Power Adapter
