Specifications
| Off grid solar power supply system- JA-HS-10KW | |||
|
System Basic Information |
Solar panel rated output power: 10KW Suitable for daily power consumption: 32KWH Allowable max loads power: 12KW |
||
| Solar panel |
Type: polycrystalline or mono solar panel Max power: 200w Vmp: 36.8V Imp: 8.3A Size: 1498*998*40mm 25 years power output guarantee (CE TUV) |
QTY 50pcs |
|
| PV Array Combiner |
Simplify wiring between PV array and controller, protections to controller, features: Wide range of DC input voltage Reliable thunderstorm& surge protection Multiple PV strings inputs Service time: 10 years, |
QTY 2pcs |
Notes: 1. pictures show are for reference. 2. power output data is based on areas with daily average peak power shine of 4.5hrs 3. the battery capacity is designed for power storage of 1.5-2 days PV output 4. solar panel rack can be specially designed based on site condition Remark: 1)solar panel have 3 years warranty; 2)other parts have 2 years warranty; 3)ship the free parts for service(best service in china) 4)accept OEM |
| Controller |
Model: 96V80A PWM charging mode intelligent control., temperature compensation, various protection functions; |
QTY 1pc |
|
| Inverter |
Pure sine wave inverter; 10kw DC input: 96v Output 110V/220v (optional) Use copper transformer; Bypass function with AC charger; LCD display |
QTY 1pc |
|
| Battery |
Capacity; 12V/200AH Solar power lead-acid battery, full sealed Service life: 5-6 years, warranty: 2 year |
QTY 40pcs |
|
| Solar panel rack |
Flat – roof type mounting rack, No welding/ cutting at site, easy mounting. More options to select: Slope-roof mounting rack Array type rack; Standing – pole type rack |
QTY 1set |
|
| Cables | International standard, with specification suitable for solar system, | 200m | |
