Home  >Products Catalog > Stone CNC Router > Jiaxin Tools Changing Stone CNC Cutting Milling Machines (JX-3015S)

Jiaxin Tools Changing Stone CNC Cutting Milling Machines (JX-3015S) SafeBuy Supplier Member

FOB Price: 20,000.00 - 40,000.00 USD/Set
Supply Ability: 10 Set/Sets per Month
Shipping: 50 days arrived QINGDAO port
Payment Terms: L/C, T/T, Western Union
In Stock
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Shandong in China
Packaging Details: Steel frame and plywood box

Quick Details

  • After-sales Service Provided: Engineers available to service machinery overseas
  • Warranty: 12 months
  • Certification: CE,CIQ,QC,SGS,
  • Weight: 5000KGS
  • Dimension(L*W*H): 3800x2200x1650mm
  • Power(W): 12.0Kw
  • Voltage: 380V/50Hz
  • Model Number: JX-3015S
  • Brand Name: JIAXIN
  • CNC or Not: CNC
  • Condition: New

Specifications

JIAXIN Tools Changing Stone CNC Cutting Milling Machines


(JX-3020S)



Model

JX-3015S

X. Y.Z work area

X axis

3000mm

Y axis

2000mm

Z axis

350mm

Model of CNC Automatic tool

ISO-40

Spindle power

12KW

CNC Tool-store

12r+12r(pieces)

Vacuum pump

50m3 /h

Max Processing Thickness

200mm

Automatic central lubricative device

grease

Electronic hand wheel button device

EHDW-BA6S-IM

Water Consumption

40L/MIN

compressed air pressure

8 Bar

Max Total Power Rate

13KW

Overall Size: L*W*H

5200X3200X2700mm

Weight

5000KG



Suitable Industry
CNC MACHINING CENTER is a type of 3-dimensional CNC processing equipment design
ed and manufactured by us to meet nowadays processing pursuit of high precision, high speed, high efficiency under the drastic competition circumstances. The machine has the functions of milling, grinding, polishing and sculpting. It is especially suitable for producing high-grade basin board and other abnormal products made of stone, ceramic, glass and micro-crystal stone. The machine will automatically finish the processing of any required profile by simple setting. The products are of high precision and good glossiness rate. Furthermore, the machine can also run CNC programs to
carry out different kinds of sculpting and mould processing etc.

Performance Characteristics
1. Software,It can be applicable for many kinds of software, such as UncGraphics. NX3.0, Mastercam9.0 and so on ,
integrating CAD/CAM, to program processing through digitized analysis and product design. It also can support files
in many formats , for example pre/igs/scep/dxf/dwp etc.
2. Auto tool-change system: The automatic system for changing tools is improving the integration all in terms of
making holes, cutting, milling, shaping and polishing.

3. Cutting wheels and abrasives: Many kinds of cutting wheels and abrasives(both imported and China-made) are
very easily available from local markets for various processing requirements

4. High precise ball screw and guide rail: The ball screw and guide rail are utilized by well-known
Germany manufacturers. Unique oil-dip lubrication is applied for X and Y axis. The special water-proof and dirt-proof
Structures can ensure better processing accuracy also prolong the life of screws and rails furthest.

Guarantee & after sale service
Guarantee for 12 months, 24-hour technical support by email or calling
User-friendly English manual and Video CD for machine using and maintaining.ecaltvv
