SM-76 Busbar Insulator

Shipping:	By Sea/By Air/By Express
Payment Terms:	L/C, T/T

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Zhejiang in China
Packaging Details:	Standard Export Package !

Specifications

Bus bar insulator(DMC insulator):

1) Material: DMC, bulk molding compound, unsaturated polymer with fiber glass
2) Good electrical resistance, heat resistance, fire resistance, low shrinkage and water resistance properties

SM-25 Tensile strength: 500lbs, Tongue strength: 6lbs, Withstanding voltage: 6kV, Screw: 6mm, Weight: 28g
SM-30 Tensile strength: 550lbs, Tongue strength: 8lbs, Withstanding voltage: 8kV, Screw: 8mm, Weight: 30g
SM-35 Tensile strength: 600lbs, Tongue strength: 10lbs, Withstanding voltage: 10kV, Screw: 8mm, Weight: 50g
SM-40 Tensile strength: 650lbs, Tongue strength: 10lbs, Withstanding voltage: 12kV, Screw: 8mm, Weight: 86g
SM-51 Tensile strength: 1,500lbs, Tongue strength: 40lbs, Withstanding voltage: 15kV, Screw: 8mm, Weight: 83g
SM-76 Tensile strength: 650lbs, Tongue strength: 10lbs, Withstanding voltage: 25kV, Screw: 10mm, Weight: 233g
