Specifications
Media converter rack, 19", 2U, 16 slots, internal power, AC100~240V(power cord with EURO (2 pole with GND) or USA standard plug (3 pole)).
Features:
◇ Supports 100Base-FX standard
◇ Built in 128Kb RAM for data buffer
◇ Supports auto MDI-MDIX function
◇ Supports link fault pass through function (LFP)
◇ Supports for end fault function (optional)
◇ LED display for link/activity, full/half, 10/100M
◇ Support EEPROM configuration (optional)
◇ The longest transmission distance reach 120 kilometers
◇ IEEE802.3 Ethernet standard, IEEE802.3u fast Ethernet standard
◇ Built in a 2-port switch
- Pass all packets without address and CRC check (optional)
- Supports modified cut-through frame forwarding for low latency
- Supports pure converter mode data forwarding for extreme low latency
- Supports flow control for full and halt duplex operation
- Bandwidth control
- Forward 1600 bytes packet for management
- Optional forward fragments
Parameter
Item
|
MCC-2U-14
|
MCC-2U-16
|
MCC-2U-16-SNMP
|
Specification
|
19”, 2U
|
19”, 2U
|
19”, 2U
|
Interface
|
14 Slots
|
16 Slots
|
16 Slots
|
Two power supply
|
Yes
|
Yes
|
Yes
|
Management
|
No
|
No
|
SNMP
|
Working temperature
|
0 ~ 60℃
|
Storage temperature
|
-10 ~70℃
|
Humidity
|
5 ~ 95%(Non-condensing)
|
Dimension
|
437x300x132mm
|
437x300x132mm
|
437x300x132mm
|
Weight
|
5.5kg
|
5kg
|
6kg
|
|
Applications
◇ Ethernet Network
◇ Fiber Optical Network
