Large size High Temp. Aging Room

FOB Price:	2,633.00 - 4,533.00 USD/Set
Supply Ability:	3 Set/Sets per Month
Shipping:	power meeting
Payment Terms:	L/C, T/T, Western Union

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	power meeting

Quick Details

power: AC-380V

Specifications

Large size High Temp. Aging Room

Burn-In Test oven/application:
High Temperature Aging Test Room is used to test various types of materials for their tolerances of heat, cold, dry, humidity. It is applied for quality inspection for all types of big test samples, such as electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.

Burn-In Chamber/features:
1. Graceful appearance, circularly shaped body, surface treated with mist strips and plane. Easy to operate, safe and reliable.
2. Rectangular double-paned viewing window for observation of sample under test,with interior lights
3. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
4. French Tecumseh is used as compressor, with environment friendly refrigeration R23, R404A
5. LCD display screen, capable of displaying set point and actual values at the same time
6. The control unit has the functions of multiples segment program editing, and of quick or ramp rates control of temperature.
7. Casters are provided for ease of mobility, with strong positioning screws.

Burn-In Test Room/technical parameters:
1. Model: TAR-volume
2. Inner Dimensions (cm): Customers designated space size and design
3. Temperature Range: RT+10℃~80℃(80℃ ~150℃ is optional)
4. Analytic Accuracy / Distribution Uniformity of Temperature: 0.1℃ /±2.5℃;
5. Control Accuracy of Temperature: ±0.5℃;
6. Temperature Rising Speed Rate: Temperature rising speed: approx. 0.1~3.0 (℃/min)
7. Cooling System: Refrigeration by compressor, according to customer’s requirements
8. Protection Devices: Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-temperature protection switch, fuses, fault warning system
9. Optional Accessories: Slope for cart, Recorder
10. Compressor French Tecumseh Brand, Germany Bizer Brand
11. Power AC 380V,50/60HZ ,3∮ 5 Lines
