1.4km small size embedded wireless transceiver module SV610 TTL port 100mW

FOB Price:	12.00 - 13.00 USD/Piece
Payment Terms:	T/T, Western Union, Other, paypal

In Stock

Inquiry Now

Related products from verified members

Optical Mechanical/Manual Splicer

Price:

Min. Order:
car door remote control

Price:100.00-500.00 USD/Piece

Min. Order:1000 Pieces

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Specifications

SV610 is highly integrated radio data transceiver module. It adopts high performance Silicon Lab Si4432 RF chip. Si4432 has low reception sensitivity and 100mW output power to ensure longer RF range and high link quality. SV610 supports multiple channels and Net ID to enhance the anti-interfere ability. Users can configure the parameters through PC or in circuit. The features of small packet, long distance, wide working voltage and setting in circuit make SV611 wildly deployed in many fields and applications.

Feature

1400 meters transmission distance @ 2.4K rate when
Working frequency options:433/470/868/915 MHz
40 channels
4 bytes network ID
2 bytes node ID
Multiple data transfer rate
RSSI output field strength
GFSK modulation mode
automatically antenna matching and bi-directional switch control
Support Serial port parameter setting
sensitivity up to -121 dBm
Maximum output power: 100 mW
Operating Voltage 2.8 ~ 6.0 V

Application

Remote telemetry
Auto meter reading
Security Systems
Data logger
home automation telemetry
personal data records
wireless data communications
building automation and security
Healthy Monitoring
wireless PC peripherals
Access Control System
robot control
