Home >Products Catalog > Ceramic capacitors > Vishay 715C30DKT50 High Voltage Disc Capacitor

Vishay 715C30DKT50 High Voltage Disc Capacitor

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Quick Details

Brand Name: MX
Model Number: 715C

Specifications

Vishay 715C30DKT50 High Voltage Disc Capacitor

Manufacturer supply high voltage disc ceramic capacitors, screw mounting, perfect Alternative replacement and direct cross of AVX, TDK, VISHAY, HVCA, CKE, Morgan Ceramics and etc…Such as,

715C15DK... 15 kVDC

715C20DK... 20 kVDC

715C30DK... 30 kVDC

715C40DK... 40 kVDC

APLICATIONS

High voltage power supply

High voltage dividers

High voltage generators

High voltage coupling devices

Gas Lasers

Electrostatic Copying Machines

X-Ray Power Supplies

Electrostatic coating and spray equipment

Rated Voltage (V): 10KV -150KVDC

Capacitance Range: 10pF - 20000pF

Operating frequency: 20KHZ~1000KHZ

Rated Voltage:15KV, 20KV, 30KV, 35KV, 40KV, 50KV, 60KV, 80KV, 100KV

Specifications,

15KV: 1500pf, 2000pf, 3300pf, 4700pf, 10000pf

20KV: 500pf, 1000pf, 1300pf, 2500pf, 3300pf, 4700pf, 6800pf

30KV: 500pf, 1000pf, 2500pf, 3300pf, 4700pf

40KV: 300pf, 500pf, 780pf, 1000pf, 1600pf, 2500pf, 3300pf

715C15DKD15, 715C15DKD20, 715C15DKD33, 715C15DKD47, 715C15DKS10

715C20DKT50, 715C20DKD10, 715C20DKD13, 715C20DKD25, 715C20DKD33

715C20DKD47, 715C20DKD68, 715C30DKT50, 715C30DKD10, 715C30DKD25

715C30DKD33, 715C30DKD47, 715C40DKT30, 715C40DKT50, 715C40DKT78

715C40DKD10, 715C40DKD16, 715C40DKD25, 715C40DKD33
