Specifications
HF2.0-150W wind turbine
Main technical data as follows:
1. Machine Type: horizontal-axis wind turbine
2. Blade form: propeller
3. Blade number: 3 pcs
4. Blade material: glass fiber reinforced plastic
5. Type of generator: permanent-magnet 3 phase AC
6. Type of tower: guy wire or free standing
Blade diameter (m): 2.0
Rated Rotated speed(r/min):400
Rated speed (m/s):8
Rated power: 150W
Max power: 250W
Output voltage (v): 24/12
Start up wind speed (m/s):3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 6
Weight of the tower top: 35kg
Tower Steel tube model (mm): φ60
speed regulation: leaning tail + electric brake
Capacity and quantity of battery: 12V100AH1 pcs
Life span: 20-25 years;
Warranty: 1 year
Can supply power for: Color TV sets, Electric fans, Lighting, Charge
Main technical data as follows:
1. Machine Type: horizontal-axis wind turbine
2. blade form: propeller
3. blade number: 3 pcs
4. balde material: glass fibre reinforced plastic
5. type of generator:permanent-magnet 3 phase AC
6. type of tower: guy wire or free standing
.Blade diameter (m): 2.2
.Rated Rotated speed(r/min): 400
Rated speed (m/s): 8
.Rated power: 200W
Max power: 300W
Output voltage (v): 24/12
Start up wind speed (m/s): 3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 6
Weight of the tower top: 45kg
Tower Steel tube model (mm):φ60
.speed regulation: leaning tail + electric brake
Life span:20-25 years;
Warranty:1 year
Capacity and quantity of battery: 12V100AH 2 pcs
Can supply power for: Color TV sets, Electric fans, Lighting, Charge
HF2.6-300W wind turbine
Main technical data as follows:
1. Machine Type: horizontal-axis wind turbine
2. blade form: propeller
3. blade number: 3 pcs
4. balde material: glass fibre reinforced plastic
5. type of generator:permanent-magnet 3 phase AC
6. type of tower: guy wire or free standing
.Blade diameter (m): 2.6
.Rated Rotated speed(r/min): 400
Rated speed (m/s): 8
.Rated power: 300W
Max power: 400W
Output voltage (v): 24/12
Start up wind speed (m/s): 3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 6
Weight of the tower top: 45kg
Tower Steel tube model (mm):φ60
.speed regulation: leaning tail + electric brake
Life span:20-25 years;
Warranty:1 year
Capacity and quantity of battery: 12V100AH 2 pcs
Can supply power for: Color TV sets, Electric fans, Lighting, Charge
HF2.8-600W wind turbine
Main technical data as follows:
1. Machine Type: horizontal-axis wind turbine
2. Blade form: propeller
3. Blade number: 3 pcs
4. Blade material: glass fiber reinforced plastic
5. Type of generator: permanent-magnet 3 phase AC
6. Type of tower: guy wire or free standing
Blade diameter (m): 2.8
Rated Rotated speed(r/min): 400
Rated speed (m/s): 8
Rated power: 600W
Max power: 750W
Output voltage (v): 24
Start up wind speed (m/s): 3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 6
Weight of the tower top: 90kg
Tower Steel tube model (mm):φ60
Speed regulation: leaning tail + electric brake
Capacity and quantity of battery: 12V100AH2 pcs
Can supply power for: Color TV sets, Washing machines, Lighting, Refrigerators
HF3.2-1KW wind turbine
1. Machine Type: horizontal-axis wind turbine
2. blade form: propeller
3. blade number: 3 pcs
4. balde material: glass fibre reinforced plastic
5. type of generator:permanent-magnet 3 phase AC
6. type of tower: guy wire or free standing
Blade diameter (m):3.2
Rated Rotated speed(r/min): 400
Rated speed (m/s): 8
Rated power: 1KW
Max power: 1.5KW
Output voltage (v): 48
Start up wind speed (m/s): 3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 6
Weight of the tower top: 95kg
Tower Steel tube model (mm):φ76
Capacity and quantity of battery: 12V100AH4 pcs
speed regulation: leaning tail + electric brake
Can supply power for: Refrigerators, Water pumps (350), Color TV sets, Washing machines, Lighting, Electric fans, Charge
Main technical data as follows:
1. Machine Type: horizontal-axis wind turbine
2. blade form: propeller
3. blade number: 3 pcs
4. balde material: glass fibre reinforced plastic
5. type of generator:permanent-magnet 3 phase AC
6. type of tower: guy wire or free standing
Blade diameter (m): 4.0
Rated Rotated speed(r/min): 400
Rated speed (m/s): 8
Rated power: 2KW
Max power: 3KW
Output voltage (v): 96
Start up wind speed (m/s): 3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 6
Weight of the tower top: 110kg
Tower Steel tube model (mm):φ89
speed regulation: leaning tail + electric brake
Capacity and quantity of battery: 12V100AH 8 pcs
Can supply power for: Refrigerators, Water pumps, Cookers, Color TV sets, Washing machines, Lighting, Electric fans, and Charge
Main technical parameter as follows:
1. Machine Type: horizontal-axis wind turbine
2. blade form: propeller
3. blade number: 3 pcs
4. blade material: glass fibre reinforced plastic
5. type of generator:permanent-magnet 3 phase AC
6. type of tower: guy wire or free standing
Blade diameter (m): 5.0
Rated Rotated speed (r/min):200
Rated speed (m/s): 10
Rated power: 3KW
Max power: 4.5KW
Output voltage (v): 220
Start up wind speed (m/s): 3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 8
Weight of the tower top(kg): 235
Tower Steel tube model (mm):φ133
Speed regulation: leaning tail + electric brake
Capacity and quantity of battery: 12V100AH18 pcs
Can supply power for: Refrigerators, Water pumps, Cookers, Color TV sets, Washing machines, Lighting, Electric fans, and Charge
Main technical parameter as follows:
1. Machine Type: horizontal-axis wind turbine
2. blade form: propeller
3. blade number: 3 pcs
4. balde material: glass fibre reinforced plastic
5. type of generator:permanent-magnet 3 phase AC
6. type of tower: guy wire or free standing
Blade diameter (m): 6.0
Rated Rotated speed (r/min): 200
Rated speed (m/s): 10
Rated power: 5KW
Max power: 7KW
Output voltage (v): 220
Start up wind speed (m/s): 3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 9
Weight of the tower top: 285kg
Tower Steel tube model (mm):φ133
speed regulation: leaning tail + electric brake
Capacity and quantity of battery: 12V200AH18 pcs
Can supply power for: Air conditioners, Refrigerators, Water pumps, Cookers, Color TV sets, Washing machines, Lighting, Electric fans, and Charge
Main technical parameter as follows:
1. Machine Type: horizontal-axis wind turbine
2. blade form: propeller
3. blade number: 3 pcs
4. balde material: glass fibre reinforced plastic
5. type of generator:permanent-magnet 3 phase AC
6. type of tower: guy wire or free standing
Blade diameter (m) :8.0
Rated Rotated speed(r/min) : 200
Rated speed (m/s) :10
Rated power: 10KW
Max power: 15KW
Output voltage (v) : 220
Start up wind speed (m/s):3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m):12
Weight of the tower top: 600kg
Tower Steel tube model (mm):φ219
Capacity and quantity of battery: 12V200AH 18 pcs
speed regulation: leaning tail + electric brake
Can supply power for: Small villages, Air conditioners, Refrigerators, Water pumps, Cookers, Color television sets, Washing machines, Lighting, Electric fans, and Charge
Main technical data as follows:
1. Machine Type: horizontal-axis wind turbine
2. Blade form: propeller
3. Blade number: 3 pcs
4. Blade material: glass fibre reinforced plastic
5. Type of generator: permanent-magnet 3 phase AC
6. Type of tower: guy wire or free standing
Blade diameter (m): 9.0
Rated Rotated speed(r/min): 200
Rated speed (m/s): 10
Rated power: 15KW
Max power: 20KW
Output voltage (v): 380V
Start up wind speed (m/s): 3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 16
Weight of the tower top: 680kg
Tower Steel tube model (mm): φ273
Speed regulation: leaning tail + electric brake
Capacity and quantity of battery: 12V200AH 30 pcs
Can supply power for:
Small villages, Air conditioners, Refrigerators, Water pumps,
Cookers, Color television sets, Washing machines, Lighting,
Electric fans and Charge
Main technical parameter as follows:
1. Machine Type: horizontal-axis wind turbine
2. blade form: propeller
3. blade number: 3 pcs
4. balde material: glass fibre reinforced plastic
5. type of generator:permanent-magnet 3 phase AC
6. type of tower: guy wire or free standing
Blade diameter (m): 10.0
Rated Rotated speed(r/min): 120
Rated speed (m/s): 12
Rated power: 20KW
Max power: 30KW
Output voltage (v): 380
Start up wind speed (m/s): 3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 18
Weight of the tower top: 750kg
Tower Steel tube model (mm):φ325
speed regulation: leaning tail + electric brake
Capacity and quantity of battery: 12V200AH 30 pcs
Can supply power for: Small villages, Air conditioners, Refrigerators, Water pumps, Cookers, Color television sets, Washing machines, Lighting, Electric fans, and Charge
Main technical data as follows:
1. Machine Type: horizontal-axis wind turbine
2. Blade form: propeller
3. Blade number: 3 pcs
4. Blade material: glass fibre reinforced plastic
5. Type of generator: permanent-magnet 3 phase AC
6. Type of tower: guy wire or free standing
Blade diameter (m): 12.5
Rated Rotated speed(r/min): 120
Rated speed (m/s): 12
Rated power: 30KW
Max power: 35KW
Output voltage (v): 380
Start up wind speed (m/s): 3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 18
Weight of the tower top: 900kg
Tower Steel tube model (mm):φ400
Speed regulation: leaning tail + electric brake
Capacity and quantity of battery: 12V200AH 60 pcs
Can supply power for: Small villages, Air conditioners, Refrigerators, Water pumps,
Cookers, Color television sets, Washing machines, Lighting,
Electric fans and Charge
HF16.0-50KW wind turbine
Main technical data as follows:
1. Machine Type: horizontal-axis wind turbine
2. Blade form: propeller
3. Blade number: 3 pcs
4. Blade material: glass fibre reinforced plastic
5. Type of generator: permanent-magnet 3 phase AC
6. Type of tower: guy wire or free standing
Blade diameter (m): 16.0
Rated Rotated speed(r/min): 100
Rated speed (m/s): 12
Rated power: 50KW
Max power: 60KW
Output voltage (v): 380
Start up wind speed (m/s): 3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 18
Weight of the tower top: 980kg
Tower Steel tube model (mm): φ450
Speed regulation: leaning tail + electric brake
Capacity and quantity of battery: 12V200AH 120 pcs
Can supply power for: Small villages, Air conditioners, Refrigerators, Water pumps,
Cookers, Color television sets, Washing machines, Lighting,
Electric fans and Charge
Service Guarantee
-
Free Service Charge
ECVV doesn't charge any service fee to Buyers for buying this product.
-
ECVV Supply
ECVV is responsible for supply, and provides product quality inspection, fund supervision and supply chain services.
-
Product Quality Commitment
ECVV China Sourcing Agent will assess the reputation and supply ability of the factory and conduct field trips to select the high-quality Chinese factories for buyers.
-
Deposit Service Commitments
In order to improve the quality of service, ECVV will charge for a 100CNY deposit for the agent purchasing order, and the deposit will be part of subsequent purchasing costs.
After paying a deposit, if the purchasing order is not completed because of unsatisfied ECVV services, ECVV will refund your deposit.
Windmill Generator from this supplier
More products from other suppliers
Can't find a suitable Supplier or product? Entrust ECVV to purchase the well-chosen Chinese products with high cost performance.
Learn More>> Start Safebuy Order
