8 or 9 Engines Glass Angle Changing Straight Edge Machine

Payment Terms:	L/C, T/T

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	standard exporting packing

Quick Details

Condition: New
Brand Name: huatian
Model Number: HZDM5223
Voltage: 220/380V
Power(W): 26KW
Dimension(L*W*H): 7700(L) x 1200(W) x2500(H)mm
Weight: 4000KG
Certification: CE

Specifications

This machine is suitable for grinding flat glass straight line edges and corners of Different sizes and thickness. Bottom edge is grinded by one diamond wheel, Resin wheel and polishing wheel each from 0 to 45° Arris angles are grindedAnd polished by 6#~9# wheels. So 10#~12# wheels are the kibbling, exactGrinding and polishing in one time. When it is 0 for 1#~5# wheels, the function isThe same with straight line machine. Machine speed can be adjusted by its steplessRegulator at random. Easy operation, high efficiency, It is better applied to architecture glass procession.

Technical Specifications:
1. Maximum grinding: 3mm
2. Grinding speeding: 500~2500m/min
3. Chamfer Angle: 0° ~ 45°
4. Thickness of processed glass: 3 ~25mm
5. Size of processed glass: Max: 3000 x 3000mm Min: 130 x 130mm
6. Total power: 26KW
7. Weight: 4000 KG
8. Size: 7700(L) x 1200(W) x2500(H)mm
