>Products Catalog > Atlas Copco > Portable Air Compressor Model XATS800Cd Atlas Copco Portable Air Compressor,XATS800
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|
Quick Details
- Condition: New
- Type: Screw
- Configuration: Portable
- Power Source: Diesel
- Lubrication Style: Lubricated
- Mute: Yes
- Brand Name: Atlas Copco
- Model Number: XATS800
- After-sales Service Provided: Overseas service center available
Specifications
Description
Specifications
Portable Air Compressor Model XATS800Cd Atlas Copco Portable Air Compressor
| Compressor Data | XATS800Cd |
| Free Air Delivery @ Normal Working Pressure | 21.9m3/min |
| Normal Working Pressure | 10.3 bar |
| Air Receiver Capacity | 63.5L |
| Fuel Tank Capacity | 293L |
| Sound Pressure Level (ISO2125) | 72 dB(A) +/- 3 |
| Maximum Ambient Temperature at sea level | 50 °C |
| Diesel Engine Data | Caterpillar C7 acert T3 |
| Cylinders | 6 |
| Horsepower Developed @ Rated Speed | 186 kW |
| Unloaded Speed / Maximum Loaded Speed | 1300 / 2000RPM |
| Engine Oil Capacity | 26 L |
| Engine Coolant Capacity | 49L |
| Outlet Valve Configuration | 1 x 2" G, 2x 3/4" G |
| Nominal working condition | Inlet pressure 1bar,Humidity0%,Temp20 °C |
| Dimensions | Standard Towing Speed 20 km/h |
| Length | 5040 mm ( within towbar ) / 3450mm (without towbar) |
| Width | 2092 mm |
| Height | 1988 mm |
| Weight ( filled with oil & coolant , Initial fuel ) | 3000kg N.W /3500 kg G.W |
