9 Spindles Automatic Flat Glass Polishing Machine

Payment Terms:	L/C, T/T

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	standard exporting packing

Quick Details

Condition: New
Brand Name: HUATIAN
Model Number: HZM9325B
Voltage: 220/380V
Power(W): 18.3KW
Dimension(L*W*H): 6700(L) X 1200(W) X2500(H)mm
Weight: 2800KG
Certification: CE

Specifications

Feature:
This machine is suitable for grinding flat glass straightline edges and corners of different Sizes and thickness. Its speed can be adjusted by stepless regulator at random.
Rough grinding, fine grinding and polishing can be completed in one procession.
It's one of the indispensable equipments for glass procession because of its easy operation, High efficiency and good quality of grinding.

Technical Specifications:
1. Maximum grinding: 3mm
2. Grinding speeding: 500~3000mm/min
3. Max arris angle: 45°
4. Thickness of processed glass: 3 ~25mm
5. Size of processed glass: Max: 3000 X 3000mm Min: 100 X 100mm
6. Total power: 18.3KW
7. Weight: 2800 KG
8. Size: 6700(L) X 1200(W) X2500(H)mm
