Kinberly Industry Co., Ltd.
China Manufacturer with main products: Stone Coated Roofing Tile Machine, Roll Forming Machine, Stone Coated Tile Production Line, Stone Coated Tile Making Machine |
stone coated roofing tile making machine
| FOB Price: | 130,000.00 - 150,000.00 USD/Unit |
|---|---|
| Payment Terms: | T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Hebei in China |
Specifications
Customer order Composition of Stone Chip Coated Metal Roofing Tile Machine
This machine is customer order ,dry part adding the heat air from the waste heat boiler After dry processing
This machine is customer order ,dry part adding the heat air from the waste heat boiler After dry processing
1.NC Bottom Glue Spray Section
Dimensions (mm): 4000×1350×850
Structure: Welded Work of U beam and Steel Sheet
Drive: 2.2kw frequency modulation motor rated 0~32 revolutions/min
Transmission: reciprocation chain
Spray motor: electric motor 0.06kw
Adsorption deducting device: 1 set
Air compressor: 1 set, 0.9 m3
Pressure glue tank: 1 set, pressure: 0.1-0.6MPa
Glue gun jet: 4 sets
Manual glue spray gun: 5 sets
Spray gun stand: 1 set
2.NC Sand Spray Chamber: 1 set
Dimensions: 3000*1850*700mm
Structure: Welded Work of U beam and Steel SheeetDuplex chain transmission driven by the same motor for glue spray section
Duplex chain transmission
Sand tank: 1, 550*600*500mm
Automatic Lift: 1 set. Lift height: 1.9 meter. Power: 300kg/hour
Sand jet: 4 set
3. First baking oven: 1 set
Dimensions: 25×0.8×1.2M
Welded structure with carbon steel
Oven chamber: sandwich walled chamber with temperature isolation between 1 mm carbon steel sheet
Automatic temperature controller: 2 sets. Controlling range: 0-160℃
Infrared fluorescent tube: 50 pcs
Transmission: reciprocation chain
Cooling device: 1 set
4.NC face glue spray equipment
Dimension: 3000×850×700
Welded structure with carbon steel
Automatic glue spray gun: 2 sets
Automatic spray assembly: 1 set. Pressure range: 0.1-0.6 MPa
Adsorption deducting device: 1 set
Manual glue pray gun: 5 sets
5.Secondary baking chamber
Dimension: 30000×850×700 mm
Welded structure with carbon steel Oven chamber: sandwich walled chamber with temperature isolation between 1 mm carbon steel sheet
Automatic temperature controller: 2 sets. Controlling range: 0-160℃
Infrared fluorescent tube: 50 pcs
Transmission: reciprocation chain of 30 meter distance.
Cooling device: 1 set
Marking device: automatic marking machine: 1 set.
General electrical control cabinet: 1 set
Productive capacity: 1500 pcs /8h shift
Overall power: 113 kw
