Jili Machinery Co., Ltd.
China Manufacturer with main products: Water Well Drilling Machine, Mining Drilling Machine, Piling Drilling Machine |
Home
>Products Catalog > Down the hole mining drilling rig > JLT7 Crawler mounted ground hole drilling rigs with air compressor
JLT7 Crawler mounted ground hole drilling rigs with air compressor
| FOB Price: | 1.00 - 9,000.00 USD/Set |
|---|---|
| Supply Ability: | 100 Set/Sets per Month |
| Shipping: | CHINA PORT |
| Payment Terms: | L/C, T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Henan in China |
| Packaging Details: | EXPORT STANDARD |
Quick Details
- Condition: New
- Type: coal mining drilling rig
- Power Type: Diesel
- Brand Name: JILI
- Model Number: JLT7
- Usage: Coal
- Warranty: 1 YEAR
- After-sales Service Provided: Engineers available to service machinery overseas
Specifications
JLT7 Crawler mounted ground hole drilling rigs with air compressor
Features:? Has a strong climbing ability and adaptive to the rough pavement?Adapt to a wide range, can be furnished with various types of DTH impactor, can drill different diameter and different depth in variety of position and angle?Also can be furnished with dry or wet dust collector when working, effectively reduce dust pollution to the environment, and protect the worker
?Anti-jamming system, safety operation
specification:
| Overall parament JLT7 | |
| Drill hole diameter | 90-105mm |
| Drill hole depth | 30m |
| Drill rod | Φ76mm X3m |
| Hammer | KQG35A |
| Rotary speed | 0-120r/min |
| Rotary torque | 1900N.m |
| Screw air compressor | |
| Air displacement | 13m3/min |
| Max.air pressure | 17bar |
| Diesel Engine | |
| Manufacturer | YC6A |
| Rated power | 180kw |
| Undercarriage | |
| Max climb capacity | 30° |
| Ground clearance | 430mm |
| Max pulling force | 25000N |
| Dust collect way | Hydraulic Laminar flow type cyclone |
