bimetal PG clamp PAGA

Payment Terms:	T/T

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Specifications

Product Show

Bimetal PG Clamp CAPG

Product Numbers:CAGA

Product description:Used for tapping or jointing copper conductor to aluminum overhead conductors AAC,AAAC, or ACSR. Forging creates a high strength clamp. Slotted holes allow adjustment for varying conductors on each side. Tap off conductor groove is lined with hot compressed copper sheet on both upper and lower parts.Contact area betwee

INTRODUCTION:

TYPE	Conductor cross-section
CAPG-A1	Cu 6-50 mm2 Al 16-70 mm2	Sing bolt
CAPG-A2	Cu 10-95 mm2 Al 25-150 mm2	Sing bolt
CAPG-B1	Cu 6-50 mm2 Al 16-70 mm2	Double bolts
CAPG-B2	Cu 10-95 mm2 Al 25-150 mm2	Double bolts
CAPG-B3	Cu 25-185 mm2 Al 25-150 mm2	Double bolts
CAPG-C1	Cu 6-50 mm2 Al 16-70 mm2	Tri-bolts
CAPG-C2	Cu 10-95 mm2 Al 25-150 mm2	Tri-bolts
CAPG-C3	Cu 25-185 mm2 Al 35-240 mm2	Tri-bolts
CAPG-C4	Cu 35-240 mm2 Al 35-300 mm2	Tri-bolts
