P12 Outdoor Rental LED Curtain Video Display, LED Curtain Screen 12mm SafeBuy Supplier Member

FOB Price: 1,800.00 - 1,900.00 USD/Square Meter
Supply Ability: 1,000 Square Meter per Month
Shipping: sea shipping/airlfight
Payment Terms: T/T, Western Union, MoneyGram
In Stock
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Guangdong in China
Packaging Details: Wooden case/carton/flight case(optional)

Quick Details

  • Brand Name: lysonled
  • Model Number: P12 outdoor led mesh display
  • Usage: Outdoor
  • Tube Chip Color: Full Color
  • Display Function: Video
  • Pixels: 12mm
  • cabinet size: 576*576mm
  • weight of cabinet: 11KG


High level color uniformity, high gray level refresh frequency.

Free angle shape assembly,adjustable angle from -15°~ 15°, meet the requirement of featured stage style.

Outdoor use, IP65 protection grade, more than 5500CD/SQM.

Equipped with fast locks, more convenient to assemble and disassemble. Strip shape module is easy to maintenance.

Waterproof connecter, with power and signal indicator lights outside of the cabinet.


Pitch/mm P12 P16 P18
Density of pixel/(dots/m2) 6944 3906 3086
Pixel composition 1R1G1B 1R1G1B 1R1G1B
Led encapsulation SMD 3535 SMD 3535 SMD 3535
Driving method 1/2 scan  static static
View angle / ° V140/H140 V140/H140 V140/H140
Average power consumption/W/M2 350W 420W 350W
Max power consumption/W/M2 850W 980W 780W
Module size/mm 288*288mm 640*20mm 720*12mm
Size of cabinet/mm 576*576mm 640*640mm 720*720mm
Refresh rate Hz/S ≥2000 ≥2000 ≥2000
Luminance of white balance ≥4500nits ≥5000nits ≥5000nits
Weight of cabinet 11KG 10.4KG 12.5KG
Operation of Environmental Temperature/°C   -20 ℃ ~ 50℃
IP rating front:IP65   back:IP54
Working vlotage 110-220 VAC/+/- 10% ; 50~60HZ
Grey scale/color displaying colors≥16.7M(synchronized)
Brightness adjustment 256 levels of each color(manually),100 levels of each color(automatically)
Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system linsn(sending card,receiving cards and Hubs); Nova
Average of non-failure life >50,000 hours
Life span >100,000hours
Functionaless dot rate <0.0001
