stainless steel fine wire cloth

FOB Price:	5.00 - 30.00 USD/Square Meter
Supply Ability:	3,000 Square Meter per Month
Shipping:	FOB Tianjin, delivry time based on order quantity
Payment Terms:	L/C, T/T, Western Union

In Stock

Inquiry Now

Related products from verified members

3L-80 Steel Fiber

Price:1.00-2.00 USD/Ton

Min. Order:1 Ton
Steel Pallet

Price:

Min. Order:

Product Details

Export Markets:	North America, South America, Southeast Asia, Africa, Mid East, Eastern Asia
Place of Origin:	Hebei in China
Packaging Details:	wooden case

Quick Details

Brand Name: BZ
Model Number: BZ-159 for window screen
Application: Fence
Material: stainless steel window screen
Wire Gauge: customized accepted
Mesh Size: customized accepted
Hole Shape: Square
Surface Treatment: Galvanized
Technique: Crimped
window screen: for fencing
window screen: for building

Specifications

Ultra-thin Stainless Steel wire mesh is a kind of woven wire mesh, it's a kind of unique products of BZ wire mesh. This type of mesh uses SS304,SS304L,SS316,SS316L,Stainless steel fine wire or other alloy as the materials. Woven by high-precision rapier looms the weave type is plain weave. The wire diameter is about 0.022mm to 0.065mm.There are lots of specifications, the mesh shape includes square and rectangular types. The width is 0.6m to 1.5m.

Ultra-thin Wire Mesh is thin and light. And because we use advanced stainless steel mesh weaving techniques, the error is very small, the mesh surface is flat ,the opening is uniform, and it has good light transmission.
Usage:Ultra-thin Stainless Steel Wire Mesh has high tension and low elongation. It's usually used in High Precision Industry, such as high density printing, the battery industry and circuit boards, ceramics, glassware printing; Ultra-thin Wire Mesh also used in some other Special areas, such as instrumentation, car windows and other types of windows' shielding net.

Following are the common specifications of ultra-thin stainless steel wire mesh:

Mesh/Inch	Aperture Size( mm)	Wire Diameter(mm)	Open Area%	Weight (kg/sq m)
16x 16	1.547	0.04	95	0.013
25 x 25	0.991	0.025	95.1	0.008
32 x 32	0.768	0.025	93.7	0.01
36 x 36	0.677	0.028	92.2	0.014
42 x 42	0.568	0.036	88.4	0.027
50x50	0.478	0.03	88.5	0.023
56x 56	0.413	0.04	83.1	0.045
63 x 63	0.363	0.04	81.1	0.05
70 x 70	0.297	0.065	67.3	0.148
80 x 80	0.254	0.063	64.2	0.159
80x 80	0.267	0.05	70.9	0.1
82x 82	0.244	0.065	62.3	0.173
82 x 82	0.256	0.053	68.6	0.115
84x 84	0.244	0.058	65.2	0.141
90 x 90	0.222	0.06	61.9	0.162
100x 100	0.196	0.058	59.5	0.168
110 x 110	0.17	0.06	54.6	0.198
120 x 120	0.151	0.06	51.2	0.216
130 x 130	0.152	0.043	60.8	0.12
150 x 150	0.141	0.028	69.6	0.059
150 x 150	0.119	0.05	49.6	0.188
160 x 160	0.115	0.043	52.9	0.148
160 x 160	0.123	0.035	60.6	0.098
180 x 180	0.111	0.03	61.9	0.081
200x200	0.091	0.036	51.3	0.13
200x200	0.099	0.028	60.7	0.078
220x220	0.0894	0.026	60	0.074
230x230	0.0804	0.03	53	0.104
250x250	0.0716	0.03	49.7	0.113
260x260	0.0756	0.022	60	0.063
280x280	0.0657	0.025	52.5	0.088
