Chain conveyor-Chain plate conveyor line

Specifications

Chain conveyor/Chain plate conveyor line
Chain conveyor chain bearing a standard roof surface , driven by a motor reducer drive, running on a dedicated track , depending on the process, and turn the roof into a linear chain .

Flat plate chain conveyors, chain conveyors also destabilize . Roof conveyor is designed for flat conveyor chain conveyors . Used to transport glass bottles, metal cans missing easy to pull , plastic containers , packages, but also transport buffet items and machine parts. Transportation equipment topped with a flat top chains have straight chain structure with scoliosis flat top chains , two systems . Chain conveyor is widely used for food , canned food, pharmaceuticals , beverages, cosmetics and cleaning products , paper products, condiments, dairy and tobacco automatic transmission, distribution , and transport connections , after packaging .

Flat top chain structure is very simple, just a circle on both sides with a hinge plate with a chain to the pin . Both sides of the hinge side of the ring and pin fixed link , called fixed hinge circle. On the other side in a circle with a hinge in the file rolling pin connection , called the active hinge circle. Activities and pin hinge circle and constitute a hinge flat top chain. When flattened chain due to the use of regular contact with the liquid substance to be , so the chain plate made of stainless steel materials , mostly , of course, also useful for engineering plastics to manufacture. Steel flat top chain hinge ring is rolled together , so there is a seam hinge circle , roundness difficult to guarantee. Will be opened when the load is large , is a weak link. With the development of plastic tooling , plastic flat top chains also recalled developed. Since the plastic plate is a flat top chain cast molding , the structure of the link plates may be necessary to adopt a more complex shape. Since the link plates has a reinforcement rib , it is possible to improve the strength of the chain. Zheng double curved hinge -style reinforcing rib straight flat top chain strength is not lower than a simple hinge roll steel flat top chains .

Flat top chain has a simple structure , light weight, ease of manufacture and maintenance advantages. The roof is flat top chain conveyor material provides a certain width horizontal bearing surfaces . Roof width is determined by the transport of materials requirements. When the chain engages with the sprocket , the chain hinge meshing with the ring itself is the site . Because of the small gap between the top plate chains arranged in parallel on both sides , therefore, only a linear movement. On the flat top chains are used to determine when loading is very important. Widely used in straight plate chain conveyor design. Multiple parallel chain conveyor belt conveyor using available instead .

Plate chain conveyors for heavy transport irregularly shaped items. A large selection of hollow roller chains with attachments chain, on both sides of the chain attachments sync with the transport direction of the plate-like member connected to form a continuous flat , thus running smoothly . The machine with a chain or roller conveyor angle can be achieved with the use of transport .
