BKJ1307/1310 Automatic Cardboard Laminator Machine

Inquiry Now

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hebei in China
Packaging Details:	1.with export standard wooden case 2.as customers' resonable requires

Quick Details

a) Function of the machine: The machine can laminate card to card together to make tags, boxes etc.

b) Structure:

Upper Feeder: 110-800 gsm paper

Lower Feeder: 180-800 gsm paper

Compressor: Compress the laminated paper and conveying them to the piling part.

Paper piling part: To pile the laminated paper

Model	1307	1310
Max. Sheet Size (WxL)	1300mmx720mm	1300mmx1000mm
Min. Sheet Size (WxL)	500mmx450mm	500mmx450mm
Thickness of Uper Paper	100~800g/㎡	100~800g/㎡
Thickness of Bottom Paper	180~800/㎡	180~800/㎡
Max. Speed	150pcs/min(Varies according to the quality of Paper)	120pcs/min(Varies according to the quality of Paper)
Lamination Precision	±0.5mm/mm(Standard and good quality paper )	±0.5m/m(Standard and good quality paper)
Total Weight	7000kg	7000kg
Total Length	10.5M	10.5M
Operation Space	3Mx13.5M	3Mx13.5M
Power	380V 3~(15hp)	380V 3~(15hp)
