Tray type IC automatic recording machine

Payment Terms:	D/P

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Quick Details

Model

KC-005-X

The fastest speed

1000CPH (the fastest 1000 grains / hour, no calculation of writing time)

On the way

Mechanical alignment

Feeding mode

Dish

Discharging mode

Dish

IC tray number

1-8 (optional)

The maximum range of movement

300 x 600mm

Suction head parameters

Can rotate 360 ° rotation step away from the precision of 0.045 °, upper and lower stroke 50mm

Placing the repeat accuracy

+/-0.002mm (XY axis servo motor control system), Z axis +/-0.01mm

Programming mode

Imaging study / keyboard input / shear, data replication

You can download IC

QFP/BGA/QFN/TSOP/PLCC/MLF (38mm IC all)

Machine size

700 * 710 * 800mm (length x width x height)

Weight

70kg

Power Supply

220V, 50Hz
