Big Air Flow Low Noise Duc Fan in Industrial Air Conditioners
| FOB Price: | 60.00 - 80.00 USD/Piece |
|---|---|
| Supply Ability: | 30,000 Piece/Pieces per Month |
| Shipping: | sample order in 1-3 days, mass production with 7-20 days |
| Payment Terms: | T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shenzhen in China |
| Packaging Details: | sealed packed with small carton and then in big carton with six or per client's request |
Quick Details
- Power Source: Electric
- Installation: Ceiling
- Material: Plastic
- Certification: CE,ROHS
- Power (W): 128
- Voltage (V): 230
- Brand Name: Hon&Guan
- Model Number: HF-200P
- Current: 0.5A
- Speed: 2500rpm
- Weight: 2.0kg
- Air Flow: 198cfm
- Air Pressure: 156Pa
- Connection Type: NMB double ball bearing
- Stall: H/L
- Warrenty: 2year
Specifications
High Air Volume Patented Inline Mix-flow Duct Fan
General Features
1. The shell is made of polypropylene plastic, one-time disposable molded, with high anti-acid function
2. Using ABS blades ,design by hydromechanics to reach the optimal air and pressure
3. Two -speed motor, imported NMB ball bearing, it's life expectancy up to 50,000 hours
4. IP44 Protection class, waterproof and dustproof more effective
5. Can be designed with a delay function, temperature sensors and humidity sensors, more of user-friendly features design
6. Operating temperature range :-20°C~60°C
Application
Mixed flow duct fan can be used for exhaust and supply ventilation systems that require high pressure, powerful airflow
with low noise, with a range of sizes including 100, 125, 150 and 200mm. Mixed flow duct fan can be used with rigid and
flexible air duct. This kind of fan is the ideal solution for air exhaust systems for rooms with high humidity such as
bathrooms and kitchens, as well as ventilation for apartments, houses, shops, cafes, restaurants, cinemas etc.
Designation
The motor is attached to the body of the fan by two quick release clips which enables the motor to rotate to provide
connection for confined spaces and removal for maintenance without removing the whole fan or duct. All models have
an option of standard which has a two speed motor or overrun timer option variable range of 1 to 30 minutes.
Motor
The single phase ball bearing motor has two speeds and is equipped with standard thermal overload protection (STOP)
with automatic restart. Motor protection rating IP44 and are fully speed controllable. Complies with part F building
regulations and designed for ambient temperatures -20~60°C. Supply voltage 110V~380V, 50/60HZz.
Mounting
The fan can be mounted in line or at either and of the duct run and at any angle. Horizontally or vertically. All fans can
be mounted in parallel to increase the volume of air or in series to increase the pressure. The casing is fitted with a
mounting plate. The mounting box can be rotated to be installed in any positon for easy installation and connection
Company Introduction:
Located in Guanlan, Longhua new district,Shenzhen,ShenZhen HongGuan Mechatronics Company Limited, with an 8000-square-meter building area, is engaging in a whole series of research and development,manufacturing,sales and service of ac fan and dc brushless fan.
As our quality and technical performance indexes hace reached the adcance world level,with the advantages such as beautiful shape,compact structure,fine processing,high air pressrue,big air volume,light weight and thin in depth,low noise,long life,environmental adaptability,low price,reliability.
