ML-FP19 Fingerprint time attendance, biometric access control,biometric access systems

Technical Specifications

·  Fingerprint capacity: 2,000

·  Card Capacity: 2,000

·  Transaction capacity: 200,000

·  Sensor Type: optical

·  Card Reader Type: EM ID card

·  Identification speed: ≤0.8S

·  USB Disk Data Download: yes

·  USB Communication: yes

·  User Name Display: display on LCD

·  Fingerprint Sensor Resolution: 500DPI

·  Fingerprint Sensor Area: 16x14mm

·  Fingerprint placement angle: 360 degree rotation allowed

·  Maximum Card Per Person: 1

·  Maximum Fingers per person: 3

·  Battery backup: yes

·  Central Processing Unit: 32bit″Cordis 5+″RISC (603 platform)

·  Identification mode: 1:N

·  Maximum Admin records storage capacity: 1,000

·  Identification mode: fingerprint/ password/ card/ fingerprint +password+card/ card + fingerprint/ card +password/fingerprint+password

· Maximum Employee ID length: numeric, 8 digits

·  Power Supply: 12V DC 2A, AC adapter included

·  Real Time Clock: Yes

·  Temperature & Humidity: Operations: 45 °C, 70%RH; Storage: 60°C , 90%RH

·  LCD Screen: 128x64 Graphics Blue LCD display with backlight

·  Buzzer: yes

·  LED: Power and Status LED light

·  Computer & OS supported: 300MHz+CPU, 128MB+RAM with Windows XP, Windows 7, Vista

·  Access Control Interface:  Connect with electronic lock power controller, Electronic lock, access controller

·  Language: multi-language selected

·  Voice: high-definition voice

·  Environment: Inside

·   Keyboard: 4 x 4 button keypads

·   Free SDK: yes

·   Alarm function: alarm when logs full

·   Wiegand output: yes

·   Wiegand input: yes

·   PC software connection mode: TCP/IP/USB/U disk

·   Network Communication Mode: TCP/IP LAN Ethernet 10/100 Base-T; USB 2.0
