Marine Dancer Group
China Manufacturer with main products: Wheel Loader, Truck Crane, Bulldozer, Motor Grader, Road Roller, Wrecker Truck, Crawler Crane, Excavator |
XCMG Brand new 215HP Motor Grader GR215
| Supply Ability: | 200 Unit/Units per Month |
|---|---|
| Shipping: | Within 5 days after receiving down payment |
| Payment Terms: | L/C, T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Jiangsu in China |
| Packaging Details: | Nude. |
Quick Details
- Brand Name: XCMG
- Model Number: GR215
Specifications
Specifications
Grader GR215 with front blade and rear ripper
1. Commins engine and imported hydraulic parts
2. Cabin with A/C
3. Optional do
Basic specification | |
Engine model | 6CTAA8.3 6CTA8.3 |
Rated power/speed | 153kW/2200rpm 160kW/2200rpm |
Dimension(LxWxH) | 8970×2625×3470mm |
Operating weight(Standard) | 16500kg |
Performance specification | |
Travelling speed ,forward | 5,8,11,19,23,38 km/h |
Travelling speed ,reverse | 5,11,23 km/h |
Tractive force(f=0.75) | 82KN |
Max. gradeability | 20% |
Tire inflation pressure | 260 kPa |
Working hydraulic pressure | 16 MPa |
Transmission pressure | 1.3~1.8MPa |
Operating specification | |
Max. steering angle of front wheels | ±50° |
Max. lean angle of front wheels | ±17° |
Max. oscillation angle of front axle | ±15° |
Max. oscillation angle of balance box | 15 |
Frame articulation angle | ±27° |
Min. turning radius using articulation | 7.3m |
Biade | |
Maximum lift above ground | 450mm |
Maximum depth of cutting | 500mm |
Maximum blade position angle | 90° |
Blade cutting angle | 28°—70° |
Circle reversing rotation | 360° |
Moldboard width X height | 4270×610mm |
