Shenzhen Huabao Technology Co., Ltd.
China Manufacturer with main products: GPS Tracker, Vehicle Diagnostic Tool, Vehicle Mobile Dvr, Personal GPS Tracker, Black Box, Vehicle Travelling Data Recorder, GPS Telematics,... |
4 CH mini digital mobile recorder with Basic SD Card car DVR
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
|---|
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|
Quick Details
- Brand Name: huabao
- Model Number: HB-HV01
Specifications
HB-HV01 model is the basic&economic SD card mobile DVR can support dual SD cards to
store the 4ch video and 4ch audio.The basic&economic model has the features of concise
appearance, flexible installation.
Features
4 video channels,4 audio channels;
H.264 video compression;
D1 or CIF resolution ;
Video storage in dual SD card ,up to 64GB+64GB;
USB,external trigger I/O supportable;
Specifications
Item | Description | ||
Operation system | Linux | ||
Video | Video input/output | 4-channel video input, 1-channel video output; 1.0Vp-p, 75Ω | |
Dual stream | Support | ||
OSD | Time & date, vehicle ID, GPS info, etc. | ||
compression | H.264 ; high performance processor | ||
Video frame rate | PAL: 100fps total NTSC: 120fps total | ||
Live View | D1 | ||
Video Bit rate | CIF: 256Kbps ~ 1.5 Mbps, 8 levels of bit rate optional HD1: 600Kbps ~ 2 Mbps, 8 levels of bit rate optional D1: 800Kbps ~ 3Mbps, 8 levels of bit rate optional | ||
Audio | Input/output | 4ch audio in/1ch audio output,100mV-500mV/100-500Ω | |
Compression | G.726 | ||
Recording | Storage media | Up to 2 SD cards, each support 64G, support SDHC standard | |
Support cyclic recording; automatically delete the earliest file | |||
Resolution | Up to 2 channels D1+ 2 channels CIF realtime each channel | ||
File format/System | ASF/ FAT32 | ||
Recording mode | Startup recording default, schedule, alarm & event trigger, manual | ||
Search | By time, type, storage device, etc. | ||
playback | Support up to 4-channel playback simultaneously, | ||
Support fast forward, fast backward, play, pause, support 2X, 4X, 8X, 16X forward or backward, support playback by time | |||
USB backup | Support USB backup | ||
Alarm input | 8-channel alarm input/ 2channels alarm output | ||
Alarm recording | Pre-recording function, 15 seconds pre-recording, post-recording 30 sec ~ 30 min adjustable | ||
Event alarm | Overspeed alarm, acceleration alarm, motion detection alarm | ||
System upgrade | Support SD card upgrade, remote upgrade | ||
Power supply & consumption | Power supply management |
1. ACC startup/shutdown 2. Delay shutdown 3. Timing startup/shutdown | |
Input voltage | DC:+8V ~ +36V | ||
Output voltage | +12V@1.5A; +5V@0.5A | ||
Power- off protection | Patent UPS power-off protection technology, ensure the integrality of record data when accidental power failure | ||
Power | < 5W in normal working state; <0.5W standby state | ||
Working environment | Temperature | -25℃ ~ +70℃(-77°F ~158°F) | |
Humidity | 20% to 95% | ||
Dimension | 112(W) x36(H) x138(D) mm | ||
Weight | Net weight:750g(1.66 LB), gross weight: 1100g(2.43 LB) | ||
