Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Zhejiang in China
Packaging Details:	Standard Export Packing

Quick Details

Condition: New
Type: Recycling Granulator
Capacity: 500-800kg/hr
Brand Name: QE
Model Number: QE4080
Material: PET
Screw Design: Single
Voltage: 380V
Power: 30KW
Dimension(L*W*H): 1700mm*1200mm*1920mm
Weight: 1950kg
Certification: CE
Warranty: 1 years
After-sales Service Provided: Engineers available to service machinery overseas

Specifications

QE Strong Crusher

QE Series Strong Crusher has wide usage scope. Its main function is to crush all sort of soft or hard plastic, crushing massive, spherical, or strip-like plastic into tiny bits to recycle. The reuse level o f plastic is increased due to this process.

Features:

·The whole machine is made of stainless steel.

·Its compact and sturdy construction decides its function would not be affected by long term usage.

·Heavy burden type bearing with oil-sealed device and soundproof ply can keep the unit from shocking and noise, and prevent the material from pollution.

·Equipped with protective device for motor and chained power-off system to ensure safe operation, and also equipped with protective device for the safe cleaning.

·Blade are made of imported material, SKD11, through special manufacture process and heat treatment, the blades become more durable.

·Special claw and paddle blade designs can crush any hard or soft material extremely easier.

·Adjustable blade can be sharpened up while blunt and reused to prolong its life.

·The separation design of the crushing chamber and material bin allows the mesh screen to discharge and clean easily.

·It has a unique cooling water cycle system, which transfers the heat produced to outside area,can prevent granulated material from lumping efficiently.

·Small type is equipped with castor for easy moving, while heavy type equipped with adjustable level pads to keep stability when working.

QE300/400 Granulators series

Type		QE3036	QE3036/P	QE3042	QE3042/P	QE4050	QE4050/P	QE4060	QE4060/P	QE4080	QE4080/P
Motor Power	kW	7.5		11		15		22		30
Rotating speed	rpm	650		650		530		530		530
Material of blades		SKD-11
Quantity of Rotating Blades	Pcs	3×6	3×2	3×7	3×2	3×8	3×2	3×11	3×3	3×11	3×3
Quantity of Fixed Blades	Pcs	2×2		2×2		2×2		2×2		2×2
Cutting chamber	mm	360×262		420×262		480×360		600×360		660×420
Max. Output	kg/hr	220-420	100-200	300-500	150-300	320-540	170-350	360-560	200-450	500-800	250-500
Regrind Conveyor		o		o		o		o		o
Cooling Device		-		-		√		√		√
Full-receiver alarm device		o		o		o		o		o
Feed hopper with magnet		o		o		o		o		o
Dust separator		o		o		o		o		o
Weight	KW	610		920		1160		1580		1950
Screen size	kg	8	16	8	16	10	20	10	20	10	20
Dimensions	mm	1100×788×1442		1100×850×1442		1560×960×1828		1560×1025×1828		1700×1200×1920
L	mm	910		910		1305		1305		1305
W	mm	788		850		960		1025		1200
H	mm	1442		1442		1828		1828		1920
A	mm	732		732		928		928		928
B	mm	360×250		420×250		480×350		600×350		660×410
C	mm	620		686		840		908		975
