Zhengzhou Focus Machinery Co., Ltd.
China Manufacturer with main products: Concrete Batching Plant, Concrete Mixing Plant, Concrete Mixer, Concrete Truck Mixer, Tower Crane, Construction Hoist, Concrete Pump,... |
Home
>Products Catalog > Concrete Batching Plant > HZS50 50cbm/h ready mixed concrete batching / mixing plant
HZS50 50cbm/h ready mixed concrete batching / mixing plant
| FOB Price: | 25,000.00 - 85,000.00 USD/Set |
|---|---|
| Supply Ability: | 20 Set/Sets per Month |
| Shipping: | within 30 days |
| Payment Terms: | L/C, T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Henan in China |
| Packaging Details: | 2-5 units of 40HQ for HZS50 precast concrete plant |
Specifications
Sizes of HZS precast concrete batching / mixing plant:
HZS25(25cbm/h) precast concrete plant , HZS35 (35cbm/h) precast concrete plant , HZS50 (50cbm/h) precast concrete plant, HZS75 (75cbm/h) precast concrete plant
Why would our clients choose FOCUS precast concrete plant with skip hopper?
On the basis of combining advantages of various foreign precast concrete plant and advanced technology, FOCUS HZS precast concrete plant adopts modular structure design, which maintains convenient installation& removal and safe, comfortable operation, with good mixing effect and high efficiency. Besides, it adopts PLC automatic logical program control and host computer all-time tracking management, with safe and reliable operation and more facilitate maintaining.
What are the main features of FOCUS precast concrete plant with skip hopper?
1. Adopting twin-shaft compulsory concrete mixer, FOCUS precast concrete plant mixes evenly and rapidly, achieving good mixing effect for all kinds of dry, semi-dry and plastic concrete;
2. Concrete batcher can be designed as underground, partially underground or fully-above ground, 3-6 hoppers are pneumatically controlled by computer with fast and accurate instruct, whole job can be done in separate or accumulative models;
3. Aggregate belt conveyor is truss-framed for easy assembly, inclination angle is normally less than 20 degrees, however, it can be up to 45°by adopting through(groovy) belt when the ground area is limited for the stationary precast concrete plant ;
4. UPS, stable performance Siemens PLC, high speed and precision weighing unit module combined with our professional control and monitoring software;
5. Full automatic and easy operated production process of material measurement, transfer, mixing and discharging.
6. Heating system and ice plant could be adopted into this precast concrete plant in severely cold and hot environment.
HZS Series concrete mixing plant with skip hopper Technical Parameters
|
model |
HZS25 |
HZS35 |
HZS50 |
HZS75 |
|
Theoretical output(m3/h) |
25 |
35 |
50 |
75 |
|
Mixer model |
JS500 |
JS750 |
JS1000 |
JS1500 |
|
Output per batch(m3) |
0.5 |
0.75 |
1 |
1.5 |
|
Aggregate batcher |
PLD800 |
PLD1200 |
PLD1600 |
PLD2400 |
|
Total power(KW) |
27 |
35 |
80 |
110 |
|
Aggregate weighing accuracy(kg %) |
(0-1500)±2% |
(0-2250)±2% |
(0-2500)±2% |
(0-4000)±2% |
|
cement weighing accuracy(kg %) |
(0-300) ±1% |
(0-400)±1% |
(0-500)±1% |
(0-800)±1% |
|
water weighing accuracy(kg %) |
(0-200) ±1% |
(0-300)±1% |
(0-300)±1% |
(0-500)±1% |
|
fly ash weighing accuracy(kg %) |
(0-300) ±1% |
(0-300)±1% |
(0-300)±1% |
(0-500)±1% |
|
additive weighing accuracy(kg %) |
(0-40) ±1% |
(0-40)±1% |
(0-40)±1% |
(0-50)±1% |
|
Discharge height(m) |
3.8-4.1 |
|||
|
Max. aggregate dia.(mm) |
60 |
60 |
80 |
80 |
|
Cement silo and screw conveyor |
On request |
|||
|
Total weight (ton) |
20 |
25 |
35 |
45 |
|
Overall dimension(LxWxH)(m) |
11.5x5.8x19.4 |
12x6x19.4 |
20.5x7.5x19.4 |
25.9x9.2x19.4 |
