150M~4.25G SFP,10G SFP+ BIDI/CWDM/DWDM Modules,40G/56G QSFP+ LR4/SR4 Modules
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
Specifications
Features
Supports 9.95Gb/s to 10.5Gb/s bit rates
Hot-pluggable XFP footprint
Maximum link length of 20km with SMF
¨1270/1330nm DFB laser Transmitter and 1330/1270nm Receiver
XFP MSA package with LC connector
No reference clock required
Loop Back Support.
+3.3V, +1.8V power supply
Power dissipation <2W
Compatible with RoHS
Built-in digital diagnostic functions
Temperature range 0°C to 70°C
Applications
10GBASE-LR at 10.3125Gbps
10GBASE-LW at 9.953Gbps
10GBASE-BX 10G Ethernet
Description
Wiitek GBX-XXXX192-L2C is compliant with the IEEE803.3ae 10Gbase-Bx. and transmission distance up to 20km on SMF.The transceiver module comprises a transmitter with a 1270/1330nm DFB laser transmitter, an integrated 1330/1270nm detector preamplifier(IDP) mounted in an optical header and a limiting post-amplifier IC. Transmitter and receiver are separate within a wide temperature range of 0℃ to +70℃ and offers optimum heat dissipation and excellent electromagnetic shielding thus enabling high port densities for 10 GbE systems.
