Furniture Pipe Making Machine

FOB Price:	50,000.00 - 300,000.00 USD/Set
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: one year
Certification: CE
Weight: 20Mt
Dimension(L*W*H): 35m*5m*3m
Power(W): 300KW
Voltage: 380V
Production Capacity: 100Mt
Application: Energy Supply Pipe
Pipe Material: Carbon Steel
Type: Pipe Mill
Condition: New

Specifications

We are new but very famous Steel pipe line manufacture in China. the diameter from 7mm-219mm, the speed from 50m/min-120m/mim

We produce the automatic, high precision, high speed production line, also we produce the steel pipe and elevator guide rail production.

We are looking for the Agent and distributor in all of world. We will supply the Best offer.

You are welcome to visit our factory, you will see our produced running production line, you will see our workshop and our technical level, we will arrange the room and board.

Model	Specification			Speed
Model	RRound Pipe O.D.(mm)	Sq.& Rect. Pipe(mm)	Thickness (mm)	Speed
TY20	Φ8-Φ20	8×8-15×15	0.3-1.2	30-120
TY32	Φ10-Φ32	10×10-25×25	0.4-2.0	30-100
TY50	Φ12-Φ50	10×10-40×40	0.5-3.0	30-90
TY60	Φ20-Φ76	15×15-60×60	0.8-3.5	30-90
TY76	Φ25-Φ76	20×20-60×60	1.5-4.0	20-80
TY114	Φ45-Φ114	35×35-90×90	1.5-4.5	20-70
TY140	Φ50-Φ140	40×40-110×110	1.5-5.0	20-60
TY165	Φ60-Φ165	50×50-130×130	2.0-6.0	20-50
TY219	Φ89-Φ219	70×70-170×170	2.0-8.0	20-50
