Hanron Lighting Co., Ltd.
China Manufacturer with main products: LED Strip, LED Neon Flex, LED Controller, LED Driver, LED Aluminum Profile, LED Connector, Addressable LED Strip |
SMD5050 LED Strip Light 60LED/M
| FOB Price: | 1.00 - 2.00 USD/Meter |
|---|---|
| Supply Ability: | 300,000 Meter per Month |
| Shipping: | Shenzhen |
| Payment Terms: | L/C, T/T |
Related products from verified members
| Export Markets: | South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | Carton |
Quick Details
- Item Type: Light Strips
- Light Source: LED
- Model Number: HR00-ACNW6012A
- Brand Name: Hanron
Specifications
SMD5050 LED Strip Light 60LED/M
Hanron Lighting Co. Limited's SMD5050 LED Flexible Strip Lighting, 60LED/Meter, waterproof &non-waterproof, 14.4W/M, 18-20lm/LED, 30,000hrs lifetime.
Features:
1. TOP SMD5050 chip, high brightness, wide beam angle, low decay.
2. Easy to install for any bending
3. Low power consumption, long life span, free maintenance
4. Working temperature: -40℃ - 50℃
5. Storage temperature:-50℃ - 60℃
6. Certification: CE & RoHs
Application:
1. Cove lighting
2. Architectural lights for canopy, corridor, window, archway
3. Backlight or edge lighting for signage
4. DIY lights for home use
5. Path and contour marking
6. Decorative lights for holiday, event, show, exhibition
7. Special light effect for art gallery and glass-made items
Item NO.
LED
LED QTY
Voltage
Power
Color
Wave Length/C. T.
Luminous Flux/M
Beam
Protect Level
HR00-ACNW6012A
SMD5050
60
DC12/DC24
14.4
NW
5500-6500K
1200LM±10%
120°
IP20/
HR00-ACWW6012A
SMD5050
60
DC12/DC24
14.4
WW
2800-3200K
1200LM±10%
HR00-ACCW6012A
SMD5050
60
DC12/DC24
14.4
CW
10000-14000K
1200LM±10%
HR00-ACY6012A
SMD5050
60
DC12/DC24
14.4
RED
620-630nm
210LM±10%
HR00-ACB6012A
SMD5050
60
DC12/DC24
14.4
YELLOW
585-595nm
180LM±10%
HR00-ACG6012A
SMD5050
60
DC12/DC24
14.4
BLUE
465-475nm
138LM±10%
HR00-ACO6012A
SMD5050
60
DC12/DC24
14.4
GREEN
520-530nm
540LM±10%
Parameter
Type
(PCS)
(V)
(W/M)
Angle
IP65/
IP67/
IP68
Notes:
1. Connect red cable to positive, black cable to negative; equip safe protector to cable outlet, confirm input voltage of is 12V before power supply concatenation, working voltage is 12V, Wrong voltage concatenation will cause permanent damage.
2. Max length for concatenation is 5M for one circuit. Make another circuit if length is over 5M. Same cable length for every circuit.
3. Ensure cable outlet of strip to be waterproof
4. Prohibit touching and operating with static.
5. Please use qualified SMPS with short circuit protection, overload protection and S.O.P. certificate.
6. Diameter of electrical cable depends on actual max output current, product power, cabling length (less 5M)and low voltage transmission cable.
7. Don't hit, squeeze strip, don't bend strip overly
8. Ensure installed surface tidy, clean and dry.
9. Avoid rain and mechanical vibration.
10. Place SMPS in ventilated and dry environment.
11. Usually only80-90% of SMPS total power is consumed
