1x4 blockess splitter mini module 0.9mm cable fankout kits
| Payment Terms: | T/T, Western Union |
|---|
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|
Quick Details
- Brand Name: yingda photonic
- split ratio: 1x4
- connectors: SC/APC
- CALBE LENGTH: 1.5METER
- cable diameter: 0.9mm
Specifications
Fiber Optic PLC (Planar lightwave circuit )Splitter mini module / Blockless type
-- with steel tube 0.9mm cable
-- with connector or without connector
Features
Low Insertion loss
Low PDL
Compact Design
Good channel-to-channel uniformity
High Reliability and Stability
Application
FTTX Systems
PON Networks
CATV Links
Optical Signal Distribution
Specification
|
Split ratio |
1x2 |
1x4 |
1x8 |
1x16 |
1x32 |
1x64 |
1x128 |
||||
|
Operating Wavelength(nm) |
1260-1620nm |
||||||||||
|
Fiber Type |
G657A1 or customer specified |
||||||||||
|
Insertion Loss (dB)P Grade |
3.8 |
7.1 |
10.2 |
13.5 |
16.5 |
20.5 |
23.8 |
||||
|
Insertion Loss (dB) S Grade |
4.0 |
7.3 |
10.5 |
13.7 |
16.9 |
21 |
24.2 |
||||
|
Loss Uniformity(dB) |
0.4 |
0.6 |
0.8 |
1.2 |
1.5 |
2 |
2.5 |
||||
|
Polarization Dependent Loss(dB) |
0.2 |
0.2 |
0.2 |
0.25 |
0.3 |
0.35 |
0.4 |
||||
|
Return Loss (dB) |
55 |
||||||||||
|
Directivity (dB) |
55 |
||||||||||
|
Wavelength Dependent Loss(dB) |
0.3 |
0.3 |
0.3 |
0.5 |
0.5 |
0.5 |
0.5 |
||||
|
Temperature Stability (-40- +85℃)(dB) |
0.4 |
0.4 |
0.4 |
0.5 |
0.5 |
0.5 |
0.5 |
||||
|
Operating Temperature |
-40- +85℃ |
||||||||||
|
Storage Temperature |
-40- +85℃ |
||||||||||
|
Split ratio |
1x2 |
1x4 |
1x8 |
1x16 |
1x32 |
1x64 |
1x128 |
|
Mini-Module Dimension(mm) |
60*7*4 |
60*7*4 |
60*7*4 |
60*12*4 |
80*20*6 |
100*40*6 |
N/A |
