film capacitor-Safety capacitor x2

FOB Price:	0.10 - 5.00 RMB/Piece
Payment Terms:	L/C

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Related products from verified members

Hard Start Kits Capacitor ( Spp5 Spp6)

Price:1.00-3.00 USD/Piece

Min. Order:200 Pieces

Product Details

Place of Origin:	Fujian in China

Quick Details

Brand Name: UTX
Type: Polypropylene Film Capacitor
Capacitance: 0.0047uF-1.0uF
Rated Voltage: 250/275VAC,50-60HZ

Specifications

Product name:Safety capacitor x2 Introduction:Product name:safety capacitor X2

product presentation

Product features

UL/ENEC-VDE/CQC international certification, has high pressure resistance, high insulation resistance, fast frequency response point, plastic shell (UL94 V-0), flame retardant epoxy filling

Scope of application:

Applicable to the connected across the power supply two or radio interference suppression filter.

Reference StandardIEC 60384-14, GBT 14472Climatic category/Passive Flammability Class40/110/56/BOperation Temperature Range85℃Rated Temperature-40℃~110℃Rated Voltage275Vac/310VacMaximum continuous DC voltage630VdcCapacitance Range0.001～4.7μFCapacitance Tolerance±10%(K), ±20%(M)(20±5℃,1KHz)Voltage ProofBetween Terminals2000Vdc(2s)(CR≤1μF)

1800Vdc(2s)(CR>1μF)Between Terminals to case2110Vac(1min)Insulation ResistanceCR≤0.33μF, IR≥3×104 MΩ

CR＞0.33μF, τ≥5 000MΩ·μF (VTest: 500V, 20±5℃, 1min)Dissipation Factor1KHz, tgδ≤0.0010

10KHz, tgδ≤0.0020 (CR≤1μF) (20±5℃)Note: The working voltage of the capacitor decreases as the temperature rises. between 85~110℃,take 85℃ as the base, the temperature rises 1℃,the rated working voltage of the capacitor decreases 1.35%.
