Single Chamber Tea Bag Pack Machine Model CCFD6

FOB Price: 40,300.00 - 50,000.00 USD/Set
Supply Ability: 30 Set(s) per Year
Shipping: 30-60 working days
Payment Terms: T/T
In Stock
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Liaoning in China
Packaging Details: Export Standard Wooden Case

Quick Details

  • Type: Filling Machine
  • Brand Name: BSIT
  • Packaging Material: Paper
  • Packaging Type: Bags
  • Application: Beverage,Chemical,Food,Medical
  • Condition: New
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Certification: meet industry standard
  • Model Number: DXDC8
  • Voltage: 380V
  • Driven Type: Electric
  • Automatic Grade: Automatic
  • Material Of Bag: Paper
  • Usage: Other
  • Condition: New
  • Voltage: 380V
  • Power(W): 2.5KW
  • Warranty: 1 year
  • After-sales Service Provided: Engineers available to service machinery overseas

Specifications

Single Chamber  Tea bag packing machine Model CCFD6
Single Chamber Tea bag packing machine Model CCFD6
Our single chamber teabag packing machines include more than 10 models machines with different structure and various functions. They could meet the packing request of tea, flower tea, herbal tea, medical tea and tea foods. these machines are using the heat-seal filter paper and the technology of heat forming. One complete machine can finish all functions automatically, such as forming, filling, bag sealing, cutting, tag pasting, thread winding, envelope sealing, feeding, date and batch number printing. Some of them could even count and put bags into box automatically.

Tea bag packing machine Model CCFD6

Features such functions as automatic ration filling, heat-sealing of tea bags, automatic plastering of cotton thread and tags, and cold-sealing of the envelope in the longitudinal direction.



Technical Parameter:

Capacity

Max.110bags/minute

Max.Filling volume

8cm3

Tea bAg dimensions

62.5mm x 50mm

Envelope dimensions

70mm x 65mm

Tag dimensions

28mm x 24mm

Thread length

210mm

Power supply

AC 380V, 1.5KW

Net Weight

565kg

Gross weight

720kg

Overall dimensions

1700mm x 900mm x 2000mm

Carton dimensions

1236mm x 1000mm x 1855mm
