Specifications
III Main technical data
3.1 Mounting dimension: 8900mm x 2250mm x 2300mm
3.2 Total weight: about 10500kg
3.3 Control system: electric control
3.4 Main forming unit driving motor power: 7.5kW
3.5 Curving motor power: 4+1.1+1.1 kW
3.6 Electric cutting motor power: 3kW
3.7 Material of rollers: 45# steel, quenched HRC 58-62
3.8 Material of roller shafts: 45# steel, adjusted
3.9 Material of cutting blade: Cr12
3.10 Step of rollers: 13 steps
3.11 Forming speed: 10000~12000 mm/min
3.12 Max span: 36m
IV Buildup and spares
1. Decoiler for coils
2. Straight panel forming unit
3. Curving panel forming unit
4. Electric control system
5. Electric mould cutter
6. Two manual clamps (for clamping the beginning seam lock between two curved panels)
7. Small C chanel bending machine
8. Lifting clamps, 8 sets
9. Lifting steeve, two pieces
10. Lock seaming machine
11. Run-out racks for straight panel and curving panel: each 8 pcs enough for 24M span
12. Bearings for roller stands of straight panel forming mschine: two pieces
13. Driving chains: two pieces
14. Hand scissors: one piece (for cutting beginning terminal of color coils)
15. Hand clamps (for clamping curved panels to let seamer seam two panels together): 4 pieces
16. Wrench: one piece
17. Operation manual and CD
