Yuhuan Fangbo Machinery Co., Ltd.
China Manufacturer with main products: Hydraulic Press, Riveting Machine, Press Machine, Gas-Liquid Booster Machine, Servo Press, Air Press, Servo Hydraulic Press, Pneumatic Press... |
Home
>Products Catalog > Hydraulic press > Special press-fitting machine for multi-station motor rotor
Special press-fitting machine for multi-station motor rotor
| FOB Price: | 1.00 - 3.00 USD/Set |
|---|---|
| Supply Ability: | 100 Set/Sets per Month |
| Shipping: | Special press-fitting machine for multi-station motor rotor BY SEA |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Zhejiang in China |
| Packaging Details: | Special press-fitting machine for multi-station motor rotor Outer with strong export wooden box;Inn |
Quick Details
- Condition: New
- CNC or Not: Normal
- Power Source: Hydraulic
- Brand Name: press-fitting machine:RIYI
- Model Number: press-fitting machine:FBY-M10TMR
- Voltage: press-fitting machine:-
- Power(W): press-fitting machine:380V
- Weight: press-fitting machine:-
- Dimension(L*W*H): press-fitting machine:-
- Certification: press-fitting machine:ISO9001:2008
- Warranty: press-fitting machine:1YEAR
- After-sales Service Provided: Overseas service center available
- press-fitting machine: HS.CODE
Specifications
Special press-fitting machine for multi-station motor rotor
Non-standard plan can be customized according to customer's demand
FBY-M10TMR
Product feature
1.Multi-station single-column press machine is mainly applied to press-fitting of steering ball studs, bearings and motor rotors etc. in auto parts industry.
2.Adoption of full oil pressure system ensures high pressure, stable operating performance, high pressure precision and large adjustment range.
3.Main shaft has two kinds of speeds, fast forward and pressurized feeding. Fast forward speed improves work efficiency while pressurized feeding speed can be adjusted optionally within certain range so as to improve product press-fitting quality and protect molds and products.
4.Multi-station single column press machine is equipped with mold base. Mold can be replaced quickly to shorten mold replacement time, reduce labor cost and floor area and increase output and improve efficiency.
5.Inching/automatic functions can be switched mutually. Automatic function can be realized through foot switch.
6.Safety protection induction device for Infrared ray operation (Optional according to customers' requirements).
Technical parameters
Specification
theoretical output pressure 100(10T)
rated oil pressure 13mpa
max stroke 200mm
max opening height 340mm
throat depth 140mm
fast-forward speed 110mm/s
return speed 100mm/s
feeding speed 10-100mm/s
number of work position 6
the size of the working table 680mm
the height of the working table 890mm
power of motor 5.5kw
mold mounting hole 32mm
power 380v
weight 1800kgs
