Hebei Secure-Net Fence Facility Co., Ltd.
China Manufacturer with main products: Whatsapp +15632889931, Marrisa, Reinforcing Mesh Welding Machine, Automatic Building Welder, Wire Mesh Machine, Fence Panel Welding Machine,... |
New CNC Welding Machine(Equipment)
| FOB Price: | 25,000.00 - 50,000.00 USD/Set |
|---|---|
| Supply Ability: | 200 Set/Sets per Month |
| Shipping: | 30 days after received the downpayment |
| Payment Terms: | L/C, T/T |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Hebei in China |
| Packaging Details: | platic bags and wooden boxes |
Quick Details
- Condition: New
- Brand Name: Secure-Nett
- Model Number: SK-2012-2500
- Usage: wire mesh fence,building wire mesh building machine,cages
- Voltage: 380v 50hz
- Dimensions: 20mx5.5mx2m
- Weight: 5ton
- Certification: ISO9001:2008
- After-sales Service Provided: Engineers available to service machinery overseas
- Welding Wire Diameter: 2.5-5.0mm
- Line & Cross Wire: Straight Cut Wire
- Welding Aperture: 50x50-300x300mm
- Power Supply: AC380V 50HZ
- Welding Width: 2500mm
- Rated Power: 800KVA
- Welding Speed: 70 times/min
- Welding Spot: 48
- Machine Weight: 4.5T
- Maximum Size: Maximum Size
Specifications
New CNC Welding Machine(Equipment)
This equipment adopts synchronous control technology,separate-phase welding and welding time is composed of digital programming of PLC system .There are two kinds of tablet PC input panel,One kind is touch panel ,another is Keyboard .The operation is more intelligent and rationalization.The machine can press the panel tightly once , and weld by several times .
On the same panel,this machine can weld 30 kinds of different size of meshs between weft and weft.That is the biggest advantages of this machine.
The machine adopts new type of high efficient welding transformer ,greatly expand the scope of welding diameters.(This fully automatic wire mesh welding machine has high degree of automation, the same time reduce a lot of manual operation).
1.Cross wire feeding way: drop from cross wire hopper automatically,position of drop wire is accurately.
2.Mesh panel pulling way:adopt the serve motor, pull the panel back and forth ,pneumatic lock the cross wire,ensure position is accurate.
3.Stacking mesh panel way: fully automatic wire mesh panel transmission mechanism,stack wire mesh panel automatic, Neatly stacked, facilitate transportation, save manpower and material resources.
If need more details,kindly check our website:
If need more details,kindly check our website:
