Home  >Products Catalog > Laser power supply > Digital 100W 150W LCD CO2 Laser Power Supply Smart Laser Power Supply

Digital 100W 150W LCD CO2 Laser Power Supply Smart Laser Power Supply

Supply Ability: 4,000 Set(s) per Month
Shipping: 7 working days after payment is received
Payment Terms: D/P, T/T, Western Union, MoneyGram
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Shandong in China
Packaging Details: carton box and foam

Quick Details

  • Output Current: 45mA
  • Output Power: 100W 150W
  • Output Voltage: 20-38KV
  • Input Voltage: 110/220V
  • Brand Name: ZYElaser
  • Model Number: MYJG100 MYJG150
  • Brand Name: ZYElaser
  • Model Number: 100W CO2 Laser Power Supply
  • Output Power: 51 - 100W
  • Output Type: Dual
  • Input Voltage: 220V
  • Output Voltage: 35kv
  • Output Current: 35ma

Specifications



Digital 100W 150W LCD CO2 laser power supply smart laser power supply

Dvanced LCD digital 150W CO2 Laser Power Supply for 1400/1650/1850mm CO2 tube for engraving or cutting machine

1.Features:

this series power supply has high stability feature. Because of low repair rate,it is widely used by most machine factories.

the high-end LCD makes display function integrate into power supply. Besides beautiful appearance, it also displays current and automatically judges fault.

External connected LCD module reduces damage rate on tube and power supply when bad wiring connection with  ammeter. Also it reduces cumbersome wiring during machine production and improves productive efficiency.

All mounting holes of 60W,80W,100W or 150W power supplies are the same which is good for assembly line mount.

Aging test:Each  must pass this test which is taken at 60 degree centigrade for 12 hours in full load status. and the power supply must start and stop at each 7 seconds for 500 times. In         this way we can ensure the  is qualified.

2. Terminal definition, indicator and test



AC: Input Voltage AC220V or AC110V

H:Laser output control(When high level,it is effective)

L:Laser output control(When low level,it is effective)

P:Water protection switch(When ground connected, it is effective)

G:Signal ground

in:Laser control signal(05V)

5V:5V/50mA signal output



3.Specification:



Item

MYJG60W

MYJG100W

MYJW100W

MYJG150W

MYJW150W

Note

Customized stable voltage type(Voltage is 170V-250V,Current is not effected)

Customized auto judge tube or PS fault type

Input voltage

AC220V/110V

Input frequency

47~440Hz

Max output voltage

24KV

28KV

28KV

34KV

34KV

Max output current

24mA

30mA

30mA

36mA

36mA

Size (LxWxH)

197x161x91

230x161x96

230x161x96

305x161x96

305x161x96

Net weight

2.1

2.8

2.9

3.6

3.7

Package size

270x190x140

310x190x140

310x190x140

380x190x140

380x190x140
