Vertical mesh knitting machine

FOB Price:	1.00 - 123.00 USD/Unit
Supply Ability:	10,000 Unit/Units per Year
Payment Terms:	L/C, D/A, D/P, T/T, Western Union

In Stock

Inquiry Now

Related products from verified members

Automatic gabion mesh knitting machine supplier...

Price:30,000.00-35,000.00 USD/Set

Min. Order:1 Set
Reed Bed Mat Knitting Machine

Price:

Min. Order:1 Set
Elastic Flat Tape Crochet Knitting Machine

Price:

Min. Order:
Computerized Collar Knitting Machine

Price:3850.00-5380.00 USD/Set

Min. Order:1 Set

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Jiangsu in China

Quick Details

Model Number: TF-500
Brand Name: taifang
Vertical mesh knitting machine: mesh knitting machine

Specifications

Application:

The machine applies to five, six types of cable 8 into a ring-shaped mesh used in line with the international advanced packaging industry, the technical requirements. Do not have cable tray packaging tray, stacking easy, free pay-off will not be distorted, do not tie a knot, easy to use, retractable linkage, computer control, automatic precision to determine a long network cable network is currently the most advanced packaging. Way into the circle without line of disk or volume movements, directly from the cable multi-layer cross-winding. Into the circle after circle line outlet hole formed. Circle Line loading tray after the outlet hole insertion of a plastic casing, the inner end of cable can be released from the plastic casing will not result in reversing or knotted.
Technique Feature:

1. Knitting machine and take the initiative to put wire frame supporting synchronization, complete the mesh network cable into the ring;

2. Servo motor cable, PLC programming control, cross-mesh evenly arranged;

3. Set aside within the outlet hole, tie a knot does not distort the implementation does not release line;

4. Standard Packaging 305 meters (1000Ft) / volume;

5. Can be customized according to box into a ring core size;
Technique Specifications:

Machinry type	TF-500
Max.speed	3000rpm
Power-line	5HPAC motor with frequency control
Tension mine	Arm-type can be re-deployed
Emit line movements	Lifting motor or hydraulic lift
Power cable	1.5KWServo Motor
Cable type	Linear sliding
Meter mode	Photoelectric Sensor
Host Power	3KWDC Motor
Electrical control	Frequency+PLC
Machine Color	Green beans (which may be customer specified)
