Home >Products Catalog > Hydraulic motor > High speed Rexroth A2FM63 piston hydraulic motor

High speed Rexroth A2FM63 piston hydraulic motor

FOB Price:	500.00 - 3,000.00 USD/Set
Supply Ability:	1,000 Set/Sets per Month
Shipping:	FOB NINGBO
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Related products from verified members

30mw Twinkling Starts-Stage / Pub / Green Laser...

Price:

Min. Order:

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Zhejiang in China
Packaging Details:	Plywood case

Quick Details

contact: Frances
Replace Rexroth: A2FM28 A2FM32 A2FM45 A2FM63 A2FM80 A2FM90 A2FM160 A2FM180

Specifications

Model A2FM series

Replace for Rexroth A2FM series hydraulic motor

Displacement 5cc-1000cc/rev

Speed 1-10000rpm

A2FM63/61W-VZL020

Displacement:63ml/r

Rotation speed:2000rpm

rotation direction:double direction

For this A2FM series hydraulic motor described now, it can be completely interchanged with Rexroth Hydraulic Motor A2FM28, A2FM32, A2FM45, A2FM56, A2FM63, A2FM80, A2FM90, A2FM107, A2FM125, A2FM160, A2FM180, A2FM200, A2FM250

This fixed axial displacement piston motor A2FM, bent axis design, suitable for hydrostatic drives in open and closed circuits. It is widely applied in mobile and industrial applications .Output speed depends on the flow capacity of the pump and the displacement of the motor. The torque increase with the pressure differential between the high and low pressure side and with increasing displacement, And it can be completely interchanged with Rexroth A2FM series hydraulic motor.

Features:

1. Counterbalance valve can be fitted

2. Option: Integrated pressure relief valve

3. Option: Integrated or built - on flushing and boost pressure valves

4. Suitable for use as pump in closed circuits

5. Long - life bearings available (sizes 250 - 1000)

6. Totally interchangeable with original Rexroth A2FM series Hydraulic Motor

A2FM32/61W-VAB010 9410189 A2FM32/61W-VAB020 9410190 A2FM32/61W-VAB040 9410192
A2FM32/61W-VBB010 9410194 A2FM32/61W-VBB020 9410195 A2FM32/61W-VBB040 9410197
A2FM45/61W-VZB010 9411581 A2FM45/61W-VZB020 9411582 A2FM45/61W-VZB040 9411584
A2FM56/61W-VAB010 9424905 A2FM56/61W-VAB020 9422129 A2FM56/61W-VAB040 9429251
A2FM56/61W-VBB010 9610664 A2FM56/61W-VBB020 9610665 A2FM56/61W-VBB040 9605544
A2FM63/61W-VAB010 9408523 A2FM63/61W-VAB020 9408524 A2FM63/61W-VAB040 9408526
A2FM63/61W-VBB010 9408514 A2FM63/61W-VBB020 9408549 A2FM63/61W-VBB040 9408551
A2FM80/61W-VAB010 9422638 A2FM80/61W-VAB020 9422089 A2FM80/61W-VBB010 9610666
A2FM80/61W-VBB020 9610667 A2FM90/61W-VAB010 9408463 A2FM90/61W-VAB020 9408464
A2FM90/61W-VBB010 9408468 A2FM90/61W-VBB020 9408469 A2FM107/61W-VAB010 9424300
A2FM107/61W-VAB020 9424093 A2FM107/61W-VBB010 9610668 A2FM107/61W-VBB020 9610669
A2FM125/61W-VAB010 9409630 A2FM125/61W-VAB020 9409634 A2FM125/61W-VBB010 9409637
A2FM125/61W-VBB020 9409638 A2FM160/61W-VAB010 9425163 A2FM160/61W-VAB020 9424094
A2FM160/61W-VBB010 9610670 A2FM160/61W-VBB020 9610671 A2FM180/61W-VAB010 9409189
A2FM180/61W-VAB020 9409190 A2FM180/61W-VBB010 9409372 A2FM180/61W-VBB020 9409373
A2FM200/63W-VAB010 2011528 A2FM250/60W-VZB010 915383 A2FM250/60W-VZB020 910653
A2FM355/60W-VZH010 920780 A2FM500/60W-VPH010 943251 A2FM500/60W-VZH010 968982

A2FM16,A2FM23,A2FMA2FM32,A2FM45,A2FM56,A2FM63,A2FM80,A2FM90,A2FM107,A2FM125,A2FM160,A2FM180 A2FM250 piston motor

Size	LA2FM			LA2FM10	LA2FM12	LA2FM16	LA2FM23	LA2FM28	LA2FM32
Displacement		Vg	cm3	10,3	12	16	22,9	28,1	32
Speed 1)		nmax	rpm	8000	8000	8000	6300	6300	6300
	p=400bar	Tmax	Nm	65	76	100	144	178	204
Size	LA2FM			LA2FM45	LA2FM56	LA2FM63	LA2FM80	LA2FM90	LA2FM107
Displacement		Vg	cm3	45,6	56,1	63	80,4	90	106,7
Speed 1)		nmax	rpm	5600	5000	5000	4500	4500	4000
	p=400bar	Tmax	Nm	290	356	400	508	572	680
Size	LA2FM			LA2FM125	LA2FM160	LA2FM180	LA2FM200	LA2FM250
Displacement		Vg	cm3	125	160,4	180	200	250
Speed 1)		nmax	rpm	4000	3600	3600	2750	2700
	p=400bar	Tmax	Nm	796	1016	1144	1272

for more information ,please contact with Frances
