5v 2a AC DC Power Adapter&Wall Chargers Application for LED Lights/LCD Monitor

Supply Ability: 100,000 Piece(s) per Month
Shipping: Shipping terms: DHL, UPS, FEDEX, TNT, EMS
Payment Terms: T/T, Western Union, Paypal
  • ECVV Safebuy Services

    According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>

  • Safebuy Service Guarantee

    Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Guangdong in China
Packaging Details: 1.Inner package:PEbag,white box or as your demand 2.Outer package:Carton or according your requirem

Quick Details

  • Connection: Plug In
  • Usage: Game Player
  • Brand Name: JP
  • Type: PLUG-IN TYPE
  • Model Number: JYH32-0502000
  • DC Connection: 5.5*2.1*10
  • Product size:: 60*39*27mm
  • Warranty: 1year
  • Certificates: UL FCC SAA GS CE&RoHS

Specifications



5v 2a AC DC Power Adapter&Wall Chargers application  for LED Lights/LCD Monitor

hot sale 5v 2a USB power AdapterChargers for mobile phone

Features

Universal Input range: 90-264V/AC

Efficiency to 75%

Continuous short circuit protection

Over voltage/current protection

No load input power: <0.3W

Leakage current: <0.1mA

UL60950-1/EN60950-1 approved

Meets CEC and Erp level VI


JYH32-0502000

OUTPUT

VOLTAGE

5V

CURRENT

2.0A

POWER (max.)

10W

RIPPLE & NOISE (max.)

100mVp-p

EFFICIENCY

75%

VOLTAGE TOLERANCE

5.0%

LINE REGULATION

1.0%

LOAD REGULATION

1.0%

SETUP, RISE TIME

100ms / 115VAC at full load

HOLD UP TIME

30ms/115VAC at full load

INPUT

VOLTAGE RANGE

90 ~ 264VAC

FREQUENCY RANGE

47 ~ 63Hz

AC CURREN (max.)

0.4A/115VAC   0.2A/230VAC

INRUSH CURRENT(max.)

COLD START 30A/115VAC  60A/230VAC

PROTECTION

OVER CURRENT

120% ~ 150% type; TYPE: cut output reset: automatic recovery

OVER VOITAGE

120% ~ 150% type; TYPE: cut output reset: automatic recovery

SHORT CIRCUIT

TYPE: cut output reset: automatic recovery

ENVIRONMENT

WORKING TEMP.

0 ~ 40

WORKING HUMIDITY

20% ~ 80% R.H non-condensing

STORAGE TEMP., HUMIDITY

-20 ~ 70   20% ~ 90% R.H

SAFETY &

EMC

DIELECTRIC STRENGTH Hi-Pot

Primary to secondary:3000Vac 10mA; Primary to shell:1500Vac 10mA; shell to secondary:1500Vac 10mA

IUSULATION RESISTANCE

Primary to secondary, Primary to shell, shell to secondary; >100M Ohms / 500VDC

LEAKAGE CURRENT

0.25mA / 240VAC

SAFETY STANDARDS

UL GS SAA KCC BSI PSE CCC

EMC STANDARDS

CE EN55022B  FCC

GREEN MODE

Noload Power Consumption Less Than 0.3W

OTHERS

MTBF

50000hrs min.  MIL-HDBK-217F (25 )

DIMENSION

60*39*27mm (L*W*H)

WEIGHT

100g/pcs
