cat5e cat6 network laying cable UTP FTP

FOB Price:	2.00 - 100.00 USD/Meter
Supply Ability:	1,000,000 Meter per Week
Shipping:	FOB SHNZHEN,CHINA
Payment Terms:	L/C, T/T, Western Union, MoneyGram

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shenzhen in China
Packaging Details:	Quantity per box:305m/roll 2rolls/box Out carton size:615358365mm G.W.:18-27kgs/box Loading Qua

Quick Details

Application: LAYING CABLE
Number of Conductors: 8
Jacket: PVC
Conductor Material: Copper
Model Number: CAT5E
Brand Name: Brthers-y
conductor material: bare copper
coated: PVC

Specifications

Basic information

Construction

UTP

Conductor

Material

Solid Bare Copper

Conductor Diameter

0.5mm/24AWG

Insulation Diameter

0.89mm

No. of Pairs

Cable Diameter

5.0mm

Type of Jacket

PVC/PE/LSZH

Characters

Rated Temperature

60℃,75℃,90℃

Reference Standard

UL444,UL1581
RoHS Complied PVC,PE or LSZH Jacket
Complies to TIA/EIA - 568 - C.2&ISO/IEC 11801

Installation Temperature

-30℃ to +50℃

Minimum Bending Radius

>4P 15D

<4P 4D

Bandwidth

100MHz ,suitable for 1000MB/S Ethernet

Packaging

Quantity per box:305m/roll 2rolls/box

Out carton size:615*358*365mm

G.W.:18-27kgs/box

Loading Quantity:

800 boxes per 20'ft container

1600 boxes per 40'GP container

2172 boxes per 40'HQ container

Application:

100Base-T

100Base-T4

100VG-AnyLAN

1000Base - T

ATM

Cable Structure:

Electrical Characteristics

Frequency (MHz)	Impedance (ohm)	Return Lose (>=Db/100m)	Attenuation (<=Db/100m)	NEXT (>=Db/100m)	ELEFEXT (>=Db/100m)	PS NEXT (>=Db/100m)	PS ELFEXT (>=Db/100m)	NVP
1	85~115	20.0	2.0	65.3	63.8	62.3	60.8	68%
4		23.0	4.1	56.3	51.7	53.3	48.7
10		25.0	6.5	50.3	43.8	47.3	40.8
16		25.0	8.2	47.3	39.7	44.2	36.7
20		25.0	9.3	48.5	37.7	42.8	34.7
31.25		23.6	11.6	42.9	33.9	39.9	30.9
62.5		21.5	17.0	38.4	27.8	65.4	24.8
100		20.1	22.0	35.3	23.8	32.3	20.8
*155	82~118	18.8	28.1	32.4	20.2	29.4	17.2
*200	82~118	18.0	32.4	30.8	18.0	27.8	15.0
*310	78~122	16.7	41.8	27.9	14.2	24.9	11.2
*350	78~122	16.3	44.9	27.1	13.1	24.1	10.1
