Professional technology MB rod mill

FOB Price:	1,000.00 - 2,000.00 USD/Unit
Supply Ability:	100,000,000 Unit/Units per Month
Shipping:	7 days
Payment Terms:	L/C, T/T, Western Union

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Henan in China
Packaging Details:	Standard export wooden case

Quick Details

Use: Ore Mining
Processing Type: Forging
Material: High Manganese Steel
Certification: DIN
Machine Type: Crusher
Type: Mine Sieving Mesh
Model Number: MB0918
Brand Name: Xinhai
Advantage: High efficiency
Trait: Save energy
Type: Even granularity of products
Shell rotary speed: 29r/min
Discharging granularity: 2.5-0.2mm

Specifications

MB Rod Mill:

1.High efficiency.

2.Save energy.

3.Even granularity of products.

MB Rod mill:

Product Introduction:

MB rod mill is widely applied to grind various ores, rocks and artificial sand in metal and non-metal mining, water resources, glass construction industries that require even granularity of products and less powder sand. Highly-efficient and energy-saving rod mill replaces engine sliding bearings support with rolling bearings support. Compared with the sliding bearing support, it can save energy about 10-20% and improves the productivity about 10-20% under the same power.

Working Principle:

Rod mill drives the shell to revolve by the reducer and the gear reducer transmission or drives down directly by the gear driven by the low speed synchronous motor. There is proper ore grinding medium-steel stick inside the shell. Under the action of centrifugal force and the friction, the medium is lifted to a certain height and fall down freely. Materials continuously enter into the shell from the feeding inlet and are crushed by moving medium. Then, they will be discharged out of the machine by the force of overflow and continuous feeding. The rod mill features even granularity, large particles and less slime. Compared to the ball mill, the size distribution curve of open-circuit rod mill is the same as that of the close-circuit rod mill. The granularity character of products has relation to the crushed ores. The rod first hit the coarse particles and then smaller ones which reduces the risk of over-crushing. When the rod goes upward spirally along the liner mixed with coarse particles, just like the grizzly screen, fine particles will pass through the gap between rods which is beneficial to crush coarse particles and make them gathered in the beat area of the medium. Therefore, the products are comparatively even with less over-crushing.

Performance Characteristics:

1.It has selective grinding function.

2.The granularity of products is comparatively even with less over-crushed particles of ores.

3.The capacity is larger than that of the same specification during the rough grinding.

Technical parameter:

Model	Shell Size(㎜)	Shell Effective Volume(m3)	Stick Load(t)	Shell Rotary Speed(r/min)	Power(kw)	Discharging Granularity(㎜)	Capacity(t/h)	Weight (t)
Model	Diameter×Length	Shell Effective Volume(m3)	Stick Load(t)	Shell Rotary Speed(r/min)	Power(kw)	Discharging Granularity(㎜)	Capacity(t/h)	Weight (t)
MB0918	φ900×1800	1	2.3	29	22	2.5-0.2	6-1.6	6.2
MB0924	φ900×2400	1.32	3.1	29	30	2.5-0.2	10-2.9	6.6
