Home >Products Catalog > HOWO 6X4 TIPPER TRUCK > Lowest Price 20ton ZZ3257N3647A 336hp Howo 6x4 Tipper Truck

Lowest Price 20ton ZZ3257N3647A 336hp Howo 6x4 Tipper Truck

FOB Price:	35,000.00 - 38,000.00 USD/Unit
Supply Ability:	100 Unit/Units per Month
Shipping:	30days
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Product Details

Export Markets:	South America, Africa, Mid East
Place of Origin:	Shandong in China
Packaging Details:	nude package

Quick Details

Dimensions (L x W x H) (mm): 6980X2496X3150
Model Number: ZZ3257N3647A
Brand Name: HOWO
Gross Vehicle Weight: 25000
Engine Capacity: > 8L
Fuel Type: Diesel
Emission Standard: Euro 2
Transmission Type: Manual
Condition: New
Horsepower: 251 - 350hp
Capacity (Load): 31 - 40t
Drive Wheel: 6x4

Specifications

Lowest Price 20Ton ZZ3257N3647A 336hp Howo 6x4 Tipper Truck
SINO HOWO Dump Truck 6x4
1. Cab model HW79
2. Engine model WD615
3. Driving axle HW16
4. Tire 12.00R20

SINO HOWO Dump Truck 6x4

Representative vehicle models		ZZ3257N3647A
CAB	Model	HW70
	Type	Standard cab
Engine	Model	WD615.87
	Rated kW/rpm	213/2200
	Maximum torque Nm/rpm	1160/1100-1600
	Displacement L	9.726
Clutch		Φ 430 Diaphragm spring clutch
Transmission		HW15710
Front axle		HF9
Driving axle		HC16
Steering system		ZF8098
Electrical system		Voltage: 24V : 2 × 12V/165Ah
Tire		12.00-20Or 11.00-20
Fuel tank capacity L		300L
Curb weight (whole vehicle / Chassis) kg		7950/6500
Total mass kg		16000
Rated contained mass kg		7920
Vehicle dimensions (l x w x h) mm		6980× 2496 ×3150
Chassis dimensions (l x w x h) mm		6500× 2496 ×2958
Wheel base mm		3800
Front suspension / Rear suspension (vehicle / Chassis) mm		1500/( 1680/1200 )
Track width (front / After) mm		2022/1850
Minimum ground clearance mm		314
Approach angle / Angle of departure (whole vehicle / Chassis) °		19/( 27/38 )
Maximum speed km/h		75
Maximum grade ability %		≥50
Minimum turning diameter m		15
Box dimensions (l x w x h) mm		4190×2300×800
Container volume m³		7.7
Notes		Optional WD615.62
