Automatic Rigid Box Line for slip case

Supply Ability:	20 Set/Sets per Month
Shipping:	25days after confirmation
Payment Terms:	L/C, T/T

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Southeast Asia, Africa, Eastern Asia
Place of Origin:	Guangdong in China
Packaging Details:	PP wrap + Wooden case

Quick Details

Type: Wrapping Machine
After-sales Service Provided: Engineers available to service machinery overseas
Certification: ISO9001
Weight: 6500kg
Dimension(L*W*H): 6800 x 4500 x 3300mm
Model Number: HM-ZD6418E
Brand Name: Hongming
Power: 28KW
Voltage: AC380V
Driven Type: Mechanical
Automatic Grade: Automatic
Packaging Material: Wood
Packaging Type: Cartons,Case
Application: Commodity,Machinery & Hardware
Condition: New
Box Folding-in Depth: 15-100mm
Finished Box Length. Max.: 600mm
Finished Box Length Min.: 100mm
Finished Box Width Max.: 400mm
Finished Box Width Min.: 50mm
Finished Box Height Max.: 130mm
Finished Box Height Min.: 12mm
Paper Sheet Thickness: 80-300gsm

Specifications

HM-ZD6418 E/C Automatic Rigid Box Line

Hongming machinery specially for making rigid box making machine,rigid box making machine, rigid box maker and rigid box line.
Jewellery Box Making Machine, Gift Box Making Machine, Necklace Box Making Machine, Watch Box Making Machine, Slip Case Box Making Machine, Clamshell Box Making Machine, Slipcase making machine.

Automatic Rigid Box Line, is the most advanced fully auto box machine by our company.It is suitable to make various types of rigid boxes for mass production, such as shoe box, mobile phone box, jewellery box,wind box,sloped box, slip case box(optional),clamshell box(optional),etc

The wrapped box's max. height is 190mm(C) and 130mm (E), with max folding-in depth being 100mm.

This machine adopts Germany ORMON PLC and man-made control electric eye tracing system, hydraulic pneumatic rectifying system, and can automatically feed paper, feed greyboard, paste four corners, spot greyboard, lift box, wrap box, fold corner edge and form box.

The feeder, gluer and conveyor are driven by Japanese Yaskawa network servo(C ) or ASDA pulse servo(E) which has continually variable transmission and enjoys high accuracy, easy adjusting, and less time consumption. Double color conveyor can avoid changing to other color belt, which is Hongming's patent. The spotter unit adopts Switzerlandmicro throttle valve, high-accuracy lead-screw(C) or squaret tooth lead-screw (E) for rectifying, enchancing the spotting accuracy to within 0.2mm. The forming unit employs Germany REXROTH linear slider and virtual cam driving system, guaranteeing the stable quality and fluent movement.

This whole machine only needs 1 or 2 operators and outputs can be about 1500-2100 boxes per hous.

1. Suitable for all kinds of rigid boxes in mass production;

2. Computer control with error auto stop and display;

3. Adopt Japanese Yaskawa network servo and Germany ORMON PLC;

4.Automatically change mould(optional);

5. Automatically feed paper and greyboard;

6. 24-hours control for glue pre-heating;

7. Input 300 product formula, and add 2G memory SD card;

8. Automatically cut and heat tape to paste the greyboard box's quad stayer (four corners), with independent man-machine control;

9. Spotter by electric eye tracing system and hydraulic pneumatic recifying system to spot correctly (spotting accuracy ≤0.2mm);

10. Wrapper can automatically and continually deliver box, wrap paper, fold corner edge, fold in and form box;

11. Automatic control system for glue viscosity(optional).

HM-ZD6418 Automatic Rigid Box Line

Model		HM-ZD6418E	HM-ZD6418C
Greyboard Size D=Length, C=Width	C(Max.)	580mm	680mm
	D(Max.)	820mm	920mm
	Thickness T	1-3mm	1-3mm
Paper Size B=Length, A=Width	A(Max.)	610mm	710mm
	A(Min.)	95mm	95mm
	B(Max.)	850mm	950mm
	B(Min.)	180mm	180mm
	Thickness	80-300gsm	80-300gsm
Paper Corner Edge	E(Max.)	125mm	125mm
Paper Corner Edge	E(Min)	10mm	10mm
Finished Box Size	L(Max.)	600mm	600mm
	L(Min.)	100mm	80mm
	W(Max.)	400mm	400mm
	W(Min.)	50mm	35mm
	H(Max.)	130mm	190mm
	H(Min.)	12mm	12mm
Folding-in Depth	Folding-in Size R	15-100mm	15-100mm
Speed	≤38pcs/min
Power/Voltage	28kw/AC380V
Net Weight	6500kg
Machine Dimension	6800 x 4500 x3300mm/6800 x 4530 x 3300mm

Note:

1.The max. size and the min. size of box are determined by the max. and min. size of cover paper.

A( Min.)≤W+2H+2T+2R≤A(Max.); B( Min.)≤L+2H+2T+2R≤B(Max.)

2.The production speed of the rigid box making machine is determined by the box size, paper and cardboard materials.

3.Seller doesn't provide air compressor. (8 atm=0.808MPA , 7.5KW compressor is needed)

4. Items 5, Items 6 and item 8 box are optional device
