Marine Sewage Treatment Plant

Payment Terms:	L/C, T/T

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Jiangsu in China

Quick Details

Brand Name: SWCM

Specifications

This plant is applicable to treat the sewage, which means human body wastes and the wastes from the toilets on vessels and which is also called " black water" , to meet the effluent standards of IMO MEPC.159(55), and discharge the effluent to overboard. It is also applicable to treat galley & shower drainage which is called " grey water" on condition that the " grey water" should be pretreated and should select a bigger capacity model to match with. Marine Sewage Treatment Plant belongs to the key devices for prevention of pollution form ships in seas and oceans according to the revised Annex IV of the International Convention of the Prevention of Pollution (MARPOL 73/78). The MEPC.2 (VI) resolution adopted on 3 December 1976 is the present guidelines on implementation of effluent standards and performance tests for STP, which is called " old standards" . This device is according to the MEPC.159(55) resolution enacted on 13 October 2006, which is called " new standards" . Summary all the rules and effluent standards as followings:

Main technical specification

Model			SWCM-
Model			10	15	20		25	30	40	50	60	80	100	150	200	250	300
LOAD	Average load (L/d)		840	1190	1540		1890	2310	3080	3780	4480	6020	7700	11200	14700	18200	23100
	Peak load (L/h)		105	149	193		237	289	385	473	560	753	963	1400	1838	2275	2888
	Organic load (kgBOD₅/d)		0.42	0.595	0.77		0.945	1.155	1.54	1.89	2.24	3.01	3.85	5. 6	7.35	9.10	11.55
Rated number of persons (men)			10	15	20		25	30	40	50	60	80	100	150	200	250	300
Maximum of persons (men)			12	17	22		27	33	44	54	64	86	110	160	210	260	330
Electricity			AC 380V,50Hz,3φ/AC 440,60Hz,3φ
Power (kW)			2.25	2.25	2.5	2.5		2.5	3.0	3.0	3.5	4.0	5.0	6.0	6.0	7.0	9.0
External dimension (mm) L×W×H			1450×1400×1600	1550 × 1500 × 1600	1650×1400×1600	1850 × 1500 × 1635		1950 × 1500 × 1635	1800× 1700× 1900	1900× 1700× 1950	2100× 1700× 2000	2500× 1900× 2150	2500 × 2000 × 2300	3150 × 24000 × 27000	4155 × 2400 × 2700	5155 × 2400 × 2700	6160 × 2400 × 2700
weight		Dry weight(kg)	1050	1150	1200	1250		1350	1500	1750	1950	2150	2900	3800	4050	5000	6000
weight		Wet weight(kg)	2100	2600	2933	3210		3928	4689	5665	6486	8100	10400	14680	18330	22100	28172
Effluent standard			BOD ≤ 525mg/L,COD ≤ 125mg/L ,TSS ≤ 5mg/L,coliform ≤ 100/100ml
