Optical Fiber Zirconia Ceramic Ferrule LC APC

Supply Ability:	6,000,000 Piece(s) per Month
Shipping:	As request
Payment Terms:	L/C, T/T, Western Union, MoneyGram

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	Standard export package.

Quick Details

Brand Name: GoodFtth
Wavelength: 1310,1550nm
Data Rate: less than 0.3dB
warranty: 5 years
Connector: SC,FC,LC,ST,MU
Model Number: WN-AC-01003

Specifications

Optical Fiber Zirconia Ceramic Ferrule LC APC

Feature:
Available for SM & MM, OD 1.25mm & 2.5mm, PC & APC
Available for SC/ST/FC/LC/MU/E2000/DIN/SMA/D4/LX. 5 connectors.
Zirconia material ensures good reliability, high precision.
Good Concentricity, ID and OD.
Compliant with RoHS, IEC and Telcodia-GR-326-Core

Parameter:
Outer Diameter: 2.4990+0.0005mm
Inner Diameter: 0.125/0.126+0.003/-0mm
Concentricity: less than 1.4um
Length: 10.5+/-0.005mm(w/o flange)

Application:
Testing equipment
FTTX+LAN
CATV
Optical communication system
Telecommunication
