Hot selling 10/100 1 port POE fiber media converter

FOB Price:	1.00 - 38.00 USD/Piece
Supply Ability:	10,000 Piece/Pieces per Month
Shipping:	1~3 working days, Shenzhen port
Payment Terms:	T/T, Western Union

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Related products from verified members

Toroidal Isolation Transformer for Charge Inver...

Price:1.00-20.00 USD/Piece

Min. Order:200 Pieces

Product Details

Export Markets:	Southeast Asia, Africa, Mid East
Place of Origin:	Guangdong in China
Packaging Details:	Stand package, customized package according to your request

Quick Details

Model Number: HD-121S/PSE-20
Brand Name: HD
Warranty: 3 years
Certification: CE,FCC, RoHS Compliant
Fiber Connector: SC or ST or FC or LC
Port: 1 PJ45 Port

Specifications

1- PORT POE AND 1-PORT FIBER

Description

PoE Ethernet media converter series include HD-121S/PSE-20,HD-111S/PSE-20A,HD-111S/PSE-20B,HD-221S/PSE-20,HD-211S/PSE-20A,HD-211S/PSE-20B, this series power supply type PoE media converters comply with IEEE 802.3af/IEEE802.3 at standard, Collection of optical fiber communication and Ethernet power supply function and the function, and comply with the IEEE 802.3 af/IEEE802.3 at standard PD terminals (such as network cameras, wireless AP, network, telephone, etc.) are linked together, greatly enriched the PoE networking flexibility.

Main Features

1 –port 10/100Mbps or 10/100/1000Mbps RJ45 port

Support network ports, lightning protection power supply input port (in order to achieve 2-level lightning protection standard)

Can offer 4/5(+),7/8(-) as the power pins or 1/2(+),3/6(-) the power pins

Support IEEE802.3af/IEEE802.3at international standard

No fan, natural cooling, small, compact, calorific value is small

Fiber port is 155Mbps single mode dual fiber SC port(the port type can be customized)

Technical Parameters

Product Name	POE Ethernet media converter
Item Number	HD-121S/PSE-20,HD-111S/PSE-20A,HD-111S/PSE-20B,HD-221S/PSE-20,HD-211S/PSE-20A,HD-211S/PSE-20B
Interface Description	One RJ45 port + one SC fiber port
Network Media	10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
	100BASE-TX: UTP category 3, 4, 5 cable (maximum 100m)
	1000BASE-TX: UTP category 5 cable or above(maximum 100m)
PoE Power Pin Assignment	End-span:1/2,3/6 (default): Mid-span:4/5,7/8(optical)
Performance Specifications	Fiber Type: single mode dual fiber, transmission distance : max 25KM, SC port HD-121S/PSE-20,HD-111S/PSE-20A,HD-111S/PSE-20B speed rate:10M/100Mbps HD-221S/PSE-20,HD-211S/PSE-20A,HD-211S/PSE-20B speed rate:10M/100/1000Mbps Ethernet Port Interface protection: IEC61000-4-2(ESD) Mean Time Between Failure (MTBF): 190,000 hours( 21 years or so)
Network Protocols & compliant Standards	IEEE 802.3i 10BASET IEEE 802.3u 100BASETX IEEE 802.3x Flow Control IEEE 802.1af DTE Power via MDI IEEE 802.3af /IEEE802.3at
LEDs Indicator	POE working status, rate, full duplex, half duplex, data link, the system
Physical Specifications	Size: 25.511699mm Weight: 0.25kg
Environmental Specifications	Operating temperature: 0 to 55°C Storage temperature: -20 to 75°C Operating humidity: 10%-90% ,non-condensing Storage humidity:10%~95% ,non-condensing
Power Support	Power supply port: Max15.4W(IEEE802.3af), Max25.5W(IEEE802.3at) Power Supply DC input : 48V,1.25A
Quality Specification	CE mark,commercial,FCC Part15 ClassB,RoHS 3 years for PoE Switch warranty

Order Information

Item Number	Descriptions
HD-121S/PSE-20	10/100 Base-TX/FX PoE Media Converter 20Km SC (Dual Fiber,Single mode) Single Port Support PoE (15.4W)(IEEE802.3af)
HD-111S/PSE-20A	10/100 Base-TX/FX PoE Media Converter 20Km SC (Single Fiber,Single mode) Single Port Support PoE (15.4W)(IEEE802.3af) (TX=1310 nm)
HD-111S/PSE-20B	10/100 Base-TX/FX PoE Media Converter 20Km SC (Single Fiber,Single mode) Single Port Support PoE (15.4W)(IEEE802.3af) (TX=1550 nm)
HD-221S/PSE-20	Gigabit Ethernet 10/100/1000Mbps PoE Media Converter 20km SC (Dual Fiber,Single mode) Single Port Support PoE (15.4W)(IEEE802.3af)
HD-211S/PSE-20A	Gigabit Ethernet 10/100/1000Mbps PoE Media Converter 20km SC (Single Fiber,Single mode) Single Port Support PoE (15.4W)(IEEE802.3af) (TX=1310 nm)
HD-211S/PSE-20B	Gigabit Ethernet 10/100/1000Mbps PoE Media Converter 20km SC (Single Fiber,Single mode) Single Port Support PoE (15.4W)(IEEE802.3af) (TX=1550 nm)

Application Diagram
